| Model | DH1-135 | DH1-150 |
| Heat Input* [kW] [Hs] | 132 | 145 |
| Air Flow Rating [m³/h] | 3200 | 4600 |
| Fuel Type | Diesel - Kerosene | Diesel - Kerosene |
| Fuel consumption [l/h] | 13 | 14 |
| Fuel Nozzle size [gph] | 2.5 | 2.5 |
| Pump presssure setting[bar] | 13 | 15 |
| Voltage [V/Hz] | 230/50 | 230/50 |
| Current Rating [A] | 4.2 | 4.8 |
| Electricl power Rating [W] | 840 | 1050 |
| Fuse Rating | T10.00A | T10.0A |
| Dimensions | ||
| Net Weight (kg) | 63.0 | 92.0 |
| Length (mm) | 1450 | 1650 |
| Width (mm) | 690 | 690 |
| Height (mm) | 958 | 1125 |
| Tank Capacity (l) | 120 | 120 |
| Operating range (h) | ~9 | ~8 |
| Standard Accessories | ||
| Fuel gauge | yes | yes |
| Handle | 1 | 1 |
| Ambient thermostat | built-in | built-in |
| Malfunction detection signal | built-in | built-in |
