| US$35,000.00-50,000.00 | 1 Piece (MOQ) |
| Engine | Sinotruk 340/380 hp | Transmission | Sinotruk 10/12-speed transmission |
| Overall Dimensions | 10396×2500×3990mm | Announced/Actual Volume | 4.1/12 - 15 cubic meters |
| Total Mass | 25000 (Kg) | Number of Girder Layers | Locally three-layered girders |
| Kerb Mass | 15800 (Kg) | Rated Mass | 9070 (Kg) |
| Fuel Tank Capacity | 400L all-aluminum fuel tank | Wheelbase | 4325 + 1350 (mm) |
| Number of Axles | 3 (Three axles) (6×4) | Front Axle Tonnage | 9-ton front axle |
| Anti-lock Braking System | ABS | Rear Axle Tonnage | 16-ton double rear axles |
| Number of Tires | 10 + 1 | Tire Specification | 12.00R - 20 original factory steel wire tires |
| Automobile Air Conditioning | Equipped with air conditioning | Additional Configurations | Automatically adjustable headlights, anti-spray device |
| Tank Material | Alloy steel (Q345B Wuhan Steel) | Cylinder Material | 6mm alloy steel of 16 manganese steel |
| Blade Material | 5mm | Head Material | 8mm alloy steel |
| Reducer | Italian TOP / Bonfiglioli / PMP reducer | Hydraulic System | American Eaton / American Sauer / Italian PMP |
| Water Supply System | 400L water tank with air pressure water supply | Heat Dissipation System | Kaitong radiator / Xinxiang radiator |
| Mixing Tank Raceway | Forged with Q345B by forging process | Discharge Chute | One-time stamping forming |
| Sub-frame | Seamless rectangular tube | Mixing Towing Wheel | Imported bearing base casting |
| Mudguard | One-time stamping formed arc-shaped mudguard | Painting Process | All in line with the standard of baking varnish process |
| Are you trader or manufacturer? | We are the original factory, we have our own workshops and professional production lines. |
| Do you accept customization? | Yes, we fully accept customized services. |
| How long is your lead time? | The delivery time is 20-40 days as common, the exact delivery time depends on the order and the current production& shipping condition. |
| What are your terms of payment? | L/C and T/T. |
| What logistics methods can you use for transportation? | We support various transportation methods: (1) Shipping by frame container, ro-ro or bulk ship. (2) For China's inland neighboring countries, we can ship the truck by road or rail. (3) For urgently needed spare parts, we can ship by express or air. |
| Can I visit your factory? | You are more than welcomed to visit our workshop, we are located in Suizhou, Hubei province. |
