| Operating weight with cab | 1900 kg |
| Operating weight with canopy | 1800 kg |
| Engine power | 13.4 kW (18 hp) @ 2,200 rpm |
| Bucket capacity | 0.015-0.056 m³ |
| Maximum travel speed (High) | 4.5 km/h |
| Maximum travel speed (Low) | 2.7 km/h |
| Maximum swing speed | 9.5 rpm |
| Bucket breakout force | 16 kN |
| Shipping length | 3707 mm |
| Shipping width | 980 / 1290 mm |
| Shipping height | 2350 mm |
| Track shoe width (std) | 230 mm |
| Boom | 1685 mm |
| Arm | 1070 mm |
| Digging reach | 3910 mm |
| Digging reach on ground | 3850 mm |
| Digging depth | 2290 mm |
| Vertical wall digging depth | 1820 mm |
| Cutting height | 3385 mm |
| Dumping height | 2370 mm |
| Minimum front swing radius | 1660 mm |
| Dozer-up | 240 mm |
| Dozer-down | 240 mm |
| Swing boom left rotation | 72 ° |
| Swing boom right rotation | 58 ° |
| Model | Yan*mar 3TNV80F-SSLY |
| Emission | EU Stage V / Tier 4f |
| System maximum flow | 55 L/min ( 14.5 gal/min) |
| System pressure | 21 MPa |
