| US$6,000.00-13,000.00 | 1 unit (MOQ) |
| Maker | Advance | ||||
| Model | 120C | ||||
| Ratio | 1.48 | 1.94 | 2.45 | 2.96 | 3.35 |
| Input speed (rpm) | 1000-2500 | ||||
| Transmission capacity ( KW/RPM) | 0.1 | 0.09 | 0.08 | ||
| Rated thrust (KN) | 25 | ||||
| Center distance(mm) | 180 | ||||
| Overhaul size (mm) | 432*440*650 | ||||
| Net weight (kg) | 200 | ||||
| Rotation direction of input shaft (viewed from output end) | Counterclockwise | ||||
| Rotation direction of output shaft | Contrary to that of input shaft,when ahead | ||||
| Mechanical efficiency | ≥96% | ||||
| Reversing time | ≤8s | ||||
| Initial oil pressure | 0.3-0.6Mpa | ||||
| Working oil pressure | 1.3-1.6Mpa | ||||
| Oil grade | SD/CC30 or SAE30 (CD/CC40 or SAE40,when summer,in torrid zone) | ||||
| Oil capacity | 7L | ||||
| Max.oil temperature | ≤80 | ||||
| Consumption of cooling water | ≥1.5t/h | ||||
| Permissible inclining | Longitudinal 10°,Transverse 15° | ||||
| Overhaul | ≥10000h | ||||
