| US$100.00-2,960.00 | 1 Set (MOQ) |
* APS main control box, size: 415*340*144 * Voltage input: 12V/220V * Depth interface: connection depth sensor * Probe interface: connect probe, transmit video and power * Display: 10 inch high brightness LED display, outdoor viewing * Record, capture photos, keyboard input * U disk stores video files for live playback. * Video 8x magnification. * One button to switch video display | |
| * Manual winch, electric winch (optional) * Winch: stamping reinforcement retaining wire * Winch frame: aluminum profile, iron (optional) | |
| * Camera material: galvanized * Camera size: Φ73mm * Camera lens material: front transparent high quartz glass Side-side quartz glass effectively prevents sanding * Camera pixels: Sony CCD camera, 750 lines * Lens angle: 120 degrees * Camera light: 9 high-brightness LED beads on the front, side-mounted LED strong light source beads (adjustable brightness) * Probe withstand voltage: pressure 20MPA, maximum pressure depth up to 2000 meters * Side camera can be 360 degrees infinite forward and reverse rotation | |
* 10 inch BNC/VGA/HDMI/USB industrial display: * Size 280 × 180 × 40mm * Aspect ratio: 16:10 * Contrast: 450:1 * Brightness: 500cd/m2 * Resolution: 1280*800 | |
| * Cable material; heat resistant material * Chengla: 280KG * Outer diameter: 8mm * Temperature resistance: 70 degrees | |
| a set of connecting cables and a set of wearing parts | |
| Other terms Optional price is subject to additional | |
| Full shipment. | |
| Negotiate | |
| 10 days delivery | |
| Carton | |
