| US$2,000.00-20,000.00 | 1 Piece (MOQ) |
| Operating weight | Kg | 15318 |
| Bucket capacity | 0.58 | |
| Engine model | / | QSB4.5 |
| Output power of engine | Kw//min | 104/2000 |
| Max.torque/engine | N.m | 586 |
| Displacement | L | 4.5 |
| Fuel tank capacity | L | 250 |
| Rated flow of main pump | L/min | 2x160 |
| Pressure of main safety valve | Mpa | 31.4/34.3 |
| Hydraulic tank capacity | L | 135 |
| Slewing speed | r/min | 13.7 |
| Digging capacity of tucket | KN | 60 |
| Digging capacity of tucket rod | KN | 65 |
| Min.turning radius | mm | 6500 |
| Travel speed | Km/h | / |
| Gradient capability | % | 70 |
| A Total length | mm | 6482 |
| B Total width | mm | 2552 |
| C Total height | mm | 3158 |
| counterweight ground clearance | mm | 1230 |
| Min.ground clearance | mm | 359 |
| Min.tail swing radius | mm | 2300 |
| Wheelbase | mm | 2800 |
| Track gauge | mm | 1920 |
| Total width of chassis | mm | 2495 |
| Distance between front axle and turning center | mm | 1700 |
| Hood height | mm | 2430 |
| The maximum digging depth of dozer | mm | 112 |
| Dozer (width / height) | mm | 2495x564 |
| A Max.digging height | mm | 8296 |
| B Max.unloading height | mm | 8085 |
| C Max.digging depth | mm | 9150 |
| D Digging depth at the range of 8feets horizontally | mm | 6684 |
| E Max.vertical digging depth | mm | 5040 |
| F Max.digging radius | mm | 4825 |
| G Max.swing height | mm | 515 |
| TYPE | MATERIAL | APPLICATION | Service |
| Bucket (GP) | Q345 | Mainly used for excavation and sand, gravel and soil and other light load operating environment. | OEM & Customized service |
| Bucket (HD) | Q345+NM400 | Mainly used for digging hard soil, mixed with a relative soft stone and clay, softer stones and other light load operating environment. | |
| Bucket(HDR) | Q345+NM400 /HARDOX400 | Used for mining hard gravel mixed with hard soil, sub-hard stone or flint, after blasting or loading, and heavy-loading. |
| Bucket Type | Usage |
| Mining Super Rock Bucket | Used in mining operations with partially blasted, high-density rock materials. |
| Rock Bucket | Used for loading crushed stones after blasting. |
| Reinforced Bucket | Used in mining and construction sites with hard objects like mixed stones in debris and soil. |
| Standard Bucket | Used for excavator loading in earthworks. |
| Cleaning Bucket | Used for dredging rivers, loading light materials; slightly larger in capacity. |
| Heavy-duty Grapple Bucket | Used for material sorting in quarrying operations; grid size adjustable based on material size. |
| Light-duty Grapple Bucket | Used for clearing debris in rivers; slightly larger in capacity. |
| Cleaning Bucket | Used for dredging rivers, loading light materials; similar to the first cleaning bucket. |
| Tilting Bucket | Based on the cleaning bucket, equipped with a leveling slope for river dredging and leveling operations. |
| V-shaped Bucket | Used for excavating trenches, customizable in size for one-pass trenching. |
| Brand | Application | |||||||
| Komatsu | PC20-7 | PC30 | PC30-3 | PC30-5 | PC30-6 | PC40-7 | PC45 | PC55 |
| PC120-6 | PC130 | PC130-7 | PC200 | PC200-1 | PC200-3 | PC200-5 | PC200-7 | |
| PC200-8 | PC210-6 | PC220-1 | PC220-3 | PC220-6 | PC220-7 | PC220-8 | PC202B | |
| PC220LC-6 | PC220LC-8 | PC240 | PC300 | PC300-3 | PC300-5 | PC300-6 | PC300-7K | |
| PC300LC-7 | PC350-6/7 | PC400 | PC400-3 | PC400-5 | PC400-6 | PC400lc-7 | PC450-7 | |
| PC600 | PC650 | PC750 | PC800 | PC1100 | PC1250 | PC2000 | ||
| HITACHI | EX40-1 | EX40-2 | EX55 | EX60 | EX60-2 | EX60-3 | EX60-5 | EX75 |
| EX100 | EX110 | EX120 | EX120-1 | EX120-2 | EX120-3 | EX120-5 | EX200-1 | |
| EX200-2 | EX200-3 | EX200-5 | EX220-3 | EX220-5 | EX270 | EX300 | EX300-2 | |
| EX300-3 | EX300-5 | EX300A | EX330 | EX370 | EX400-1 | EX400-2 | EX400-5 | |
| EX450 | ZAX30 | ZAX55 | ZAX200 | ZAX200-2 | ZAX330 | ZAX450-1 | ZAX450-5 | |
| ZX110 | ZX120 | ZX200 | ZX200 | ZX200-1 | ZX200-3 | ZX200-5g | ZX210 | |
| ZX210-3 | ZX210-3 | ZX210-5 | ZX225 | ZX240 | ZX250 | ZX270 | ZX330 | |
| ZX330 | ZX350 | ZX330C | ZX450 | ZX50 | ||||
| Caterpillar | E200B | E200-5 | E320D | E215 | E320DL | E324D | E324DL | E300L |
| E320S | E320 | E320DL | E240 | E120-1 | E311 | E312B | E345 | |
| E324 | E140 | E300B | E330C | E120 | E70 | E322C | E325 | |
| E325L | E330 | E450 | CAT225 | CAT312B | CAT315 | CAT320 | CAT320BL | |
| CAT330 | CAT322 | CAT245 | CAT325 | CAT320L | CAT973 | |||
| Sumitomo | SH120 | SH120-3 | SH200 | SH210-5 | SH200 | SH220-3 | SH220-5/7 | SH350-5/7 |
| SH220 | SH280 | SH290-7 | SH260 | SH300 | SH300-3 | SH300-5 | SH60 | |
| SH430 | ||||||||
| KOBELCO | SK120-6 | SK120-5 | SK210-8 | SK210LC-8 | SK220 | SK220-1 | SK220-3 | SK200 |
| SK200 | SK200 | SK200-3 | SK200-6 | SK200-8 | SK200-5/6 | SK60 | SK100 | |
| SK230 | SK250 | SK250-8 | SK260LC-8 | SK300 | SK300-2 | SK300-4 | SK320 | |
| SK330-8 | SK330 | SK350LC-8 | SK235SR | SK450 | SK480 | SK30-6 | ||
| DAEWOO | DH200 | DH220-3 | DH220 | DH220S | DH280-2 | DH280-3 | DH55 | DH130 |
| DH370 | DH80 | DH500 | DH450 | /DH225 | ||||
| HYUNDAI | R60-5 | R60-7 | R60-7 | R80-7 | R200 | R200-3 | R210 | R210-9 |
| R210LC | R210LC-7 | R225 | R225-3 | R225-7 | R250 | R250-7 | R290LC | |
| R290LC-7 | R320 | R360 | R954 | |||||
| KATO | HD512 | HD1430 | HD 512III | HD 820III | HD820R | HD1430III | HD700VII | HD250SE |
| HD400SE | HD550SE | HD1880 | ||||||
| DOOSAN | DX225 | DX225LCA | DX258 | DX300 | DX300LCA | DX420 | DX430 | |
| VOLVO | EC160C | EC160D | EC180B | EC180C | EC180D | EC210 | EC210 | EC240B |
| EC290 | EC290B | EC240 | EC55 | EC360 | EC360B | EC380D | EC460B | |
| EC460C | EC700 | EC140 | EC140B | EC160B | ||||
