Rotary Sifter

Product Description

About Us Headquartered in Xinxiang City, Henan Province, China, domestic well-known screening and conveying equipment city, PK Machinery has enjoyed more than 50 steady years of successful growth, and now it has been widely acknowledged as a trustworthy and professional manufacturer in the field of bulk material handling equipment, including vibrating screen, vibrating feeder, belt conveyor, bucket elevator, screw conveyor, scraper chain conveyor and associated spare parts in complete specifications.

Product Description History of PK rotary sifter (gyratory screen)
As the first one manufacturer of this type screen in China, PK Machinery Co., Ltd start to design and produce this type screen from the first half of the 1998, and PK Machinery Co., Ltd has supplied hundreds sets of gyratory screen in China market in the last 15 years. PK Machinery also export this type screen to oversea successfully.
PK Machinery Co., Ltd accumulate plenty experience on this type screen in the last 15 years, we improve and develope this screen continuously during equipment operation and according the advice of the customer of PK rotary sifter (gyratory screen).
Following is the brief introduction of this type screen, if you interested in PK gyratory screen, please feel free to leave me your message and we will you reply you back soon.
Brief introduction
We call this type screen gyratory screen because it do a circle movement on a almost horizontal plane. We mainly use it for screening urea granulation and other fertilizer, but it also could handle other bulk and fine material such as grain, sand and salt.
We had supplied hundreds sets of type screen own plenty experience on this equipment.
1. Features of rotary sifter
Gyratory Vibrating Screen is a new kind of screen machine especially for urea, ferlizer, grain, cereal such as granular material. There are following advantages: Reasonable design, stable running, full-sealed construction, no dust pollution, plugged hole proof, sticking proof etc. It is more obvious to carbamide screening with strong hygroscopicity, big viscosity, easy plugged hole and sticking. Reduce validly base dynamic load for adopting rotary principle.
2. Application of vibrating screen
Gyratory Vibrating Screen is a new screening device which is developed mainly aiming at screening of bulky urea and fertilizer, also used widely for agriculture to screen grain and cereal.
3. Advantages of vibrating screen
1) No vertical vibrating and long span life sieve mesh(from 6 to 12 months)
2) Sieve mesh anti clogging clearing device is set up on each layer of mesh. The unplugged hole of mesh prolongs running period. Sieve classifier constantly clears the sieve mesh under working condition.
3) Adopting rotary principle improves obviously materials distribution, increase effective utilization of screen deck, finally increase the screen efficiency and reduce powder content of finished materials.
4) Full-sealed construction and no dust pollution improve working circumstance of operation sales person.
5) Reduce dynamic load 3 to 5 times to base.
If you interested in this type screen, please feel free to contact us, we will answer all your question on this equipment. Product Parameters

No. of Deck	Model	Screen Surface Size (W*L)	Screen Box Motion Stroke	Capacity	Motor
					Power	Rotate Speed
		(mm)	(mm)	Ton/h	(kw)	(rpm)
1-3	PXZS 1224	1200*2400	75-90	5-10	5.5	1450
	PXZS 1230	1200*3000		7-14	5.5	1450
	PXZS 1236	1200*3600		7-20	5.5	1450
	PXZS 1524	1500*2400		10-22	5.5	1450
	PXZS 1530	1500*3000		10-25	5.5	1450
	PXZS 1536	1500*3600		15-30	5.5	1450
	PXZS 1824	1800*2400		20-35	7.5	750
	PXZS 1830	1800*3000		25-40	7.5	750
	PXZS 1836	1800*3600		35-70	7.5	750
	PXZS 1842	1800*4200		60-80	7.5	750
	PXZS 2036	2000*3600		60-80	7.5	750

---
