1′′ Polyester Webbing Sling with Standard in ASME B30.9.

US$0.30 1,000 Pieces (MOQ)

Basic Info.

Model NO.
2Ton
Lifting Capacity
2T
Fixed Form
Sewn Type
Lifting Eye Type
Flat Eye
Rope Core Type
Noting
Shape
Flat
Certification
GS, CE, ISO 9001
Sling Color
Yellow
W.L.L(Lbs)
2000
Sling Safety Factor
5:1
Width
25mm
Standard
ASME B30.9
Color Code
Yellow
Transport Package
Carton
Specification
100% Polyester
Trademark
D. L. T SLING
Origin
China
HS Code
56090000
Production Capacity
1000000 PCS Per Month

Packaging & Delivery

Package Size
56.00cm * 36.00cm * 24.00cm
Package Gross Weight
24.000kg

Product Description

Material:Polyester / Nylon
Minimun Safety Factor:5:1
Length: As required
Working temperature range:-40ºC-100ºC Standard:ASME B30.9 WSTDA-WS-1
We make these products according to ASME B30.9, WSTDA-WS-1, Customers could choose special length base on special require.

Series
Stock No Color
Type I, II, III, and IV Two-leg or Single Basket type V

Single-leg Horizontal Angle
Hitch Type Width ,in.
Vertical
choke		 vertical basket vertical basket
60 deg
45 deg
30 deg		 Endless Vertical

Width ,in.








Class 5		 EE5501 1 2200 1760 4400 4400 3800 3100 2200 4400
EE5501.5 1 1/2 3300 2640 6600 6600 5700 4700 3300 6600
EE5501.75 1 3/4 3800 3040 7600 7600 6600 5400 3800 7600
EE5502 2 4400 3520 8800 8800 7600 6200 4400 8800
EE5503 3 6600 5280 13200 13200 11400 9300 6600 13200
EE5504 4 8200 6560 16400 16400 14200 11600 8200 16400
EE5505 5 10200 8160 20400 20400 17700 14400 10200 20400
EE5506 6 12300 9840 24600 24600 21300 17400 12300 24600

Class 7		 EE7501 1 3100 2480 6200 6200 5400 4400 3100 6200
EE7501.5 1 1/2 4700 3760 9400 9400 8100 6600 4700 9400
EE7501.75 1 3/4 5400 4320 10800 10800 9400 7600 5400 10800
EE7502 2 6200 4960 12400 12400 10700 8800 6200 12400
EE7503 3 8800 7040 17600 17600 15200 12400 8800 17600
EE7504 4 11000 8800 22000 22000 19100 15600 11000 22000
EE7505 5 13700 10960 27400 27400 23700 19400 13700 27400
EE7506 6 16500 13200 33000 33000 28600 23000 16500 33000
EE7508 8 22750 18200 42350 42350 36700 29900 22750 42350
EE7510 10 28400 22720 52900 52900 45800 37400 28400 52900
EE7512 12 34100 27280 63500 63500 55000 44900 34100 63500

Detailed Photos
