Computerized Flat Embroidery Machine Embroidery Sewing Machine

Product Description

Computerized Flat Embroidery Machine Embroidery Sewing Machine Technical parameter for industrial embroidery machines for sale/single head cap and t-shirt flat embroidery machine

Modle	KT1201	KT1501
Product name	1 head embroidry machine	1head embroidery machine
Needles(colors)	12pcs	15pcs
Heads	1pc	1pc
Speed	1200spm	1200spm
Control system	Newest 7"Topwishdom computer	Newest 7" Topwishdom computer
Emb.Area(each model)	360*510mm	360*510mm
Weight	160kgs	160kgs
Meas	830*830*930mm	830*930*940mm

A.Embroidery machine features:
1.Suitable for Cap, T-shirt, Finished Garments, Shoes, Socks, Pocket and Cloth embroidery
2.Automatic thread trimmer
3.Maximum speed 1200 SPM
4.270-degree wide angle caps system
5.Color LCD display showing real time stitching
6.20,000,000 Stitches matched with 200 patterns
7. Auto start and color change, 200 times color change setted
8.Compatible with designs of Tajima(DST), Barudan(DSB) and etc.
9.Design Input By U disk, USB, and Transmission from PC to Control System.
10.Thread break detection
11.Emergency stop, Error code message
12.Electricity:Ac110V-240V,50-60Hz self adaptable
13.Equip bobbin winder
14.Keeping current data or work when emergency stop or pow off
15. Mending function. (back and skip stitches under controller)
16.Switch for Cap/Flat Embroidery mode eliminating hitting the frame
17.USB port with fast data transmission and good compatibility
18. Mainboard intergated into control panel protecting from dust or extemal force.
19. Lay-out of keys on panel is user-friendly.
20.Built-in Network.
B.Control panel of embroidery machine
A. Newest 7'' Topwisdom full-color LCD display showing real time stitching
B.Manual, Semi-auto, Auto color change
C. Function Keys including Menu, Speed up and slow
D.Frame-moving keys, Manual Trimming
E.Dot ket to return to 100 degree
F. Start, Stop, and emergency Stop
G.Embroidery Status(page up / page down),USB Input
H.parameter Setting,Clear,ESC,Enter,etc
I. Numeric keys for selection of needles
J.Multilanguage:Chinese,English,French,Russian,Dutch,Spanish,Portuguese,Turkish,German,Arabic,Thai, Vietnamese
C.The Main parts of the embroidery machine
1.Japan Rotary Hook
2.Japan Bobbin case
3.Japan Bobbin
4.Italy Belt
5.Germany Groz-Beckert Needles
D.Red laser positioning device
The machine with Red laser position device can clearly see the embroidery position.
E.Hoops/frames of each head
2pcs Shirt Front Round Hoop 90mm(3.5'')
2pcs Shirt Front Round Hoop 120mcm(4.7'')
2pcs Shirt Front Round Hoop 150mm(5.9'')
2pcs Shirt Front Round Hoop 200mm(7.8'')
2pcs Shirt Front Round Hoop 290*290mm(12*12'')
F.Cap attachment of each head
1pcs Cap Driver
1pcs Cap Hoop station
2pcs Cap Hoops
G.Accessories parts
1.Extended table top for embroidery machine
2.Standing table with wheels
3.Operation manual
4.Tool kit
5.8 GB USB driver
6.Bobbin winder And so on
H.Free gift for you
1.Wooden case & vacuum package;
2.Free Digitzing software;
3.A whole set free easy damaged spare parts for your future replacement;4.50 free designs for testing your machine.

FAQ:
Q: Is this a trustable long-term strategic partner?
A: Just ask our customers, view our company profile, assessment of capability, factory glimpse, and the honor we had.
Q: What service will I get with this buying?
A: Simply at your service: available consultancy before sales, easy communication during sales, easy payment term, smooth and safe delivery of guaranteed quality, and assured timely services after sales.
Q: What kind of embroidery work and embroidery machine do I need?
A: Think: ready-made garment/cap/hat, or garment before sewing, or just flat fabric?
Normal flat stitch, or special chenille/chain/loop stitch, or sequin/paillette, or cord/tape/ribbon to add value to your embroidery?
Q: How many heads do I need and what embroidery area on each head?
A: Think: how big is your factory and how much is your expected production?
The embroidery area on each head depends on the maximum area of your embroidery design to run.
Q: How many stitches do I get per minute (SPM) on each head?
A: Super high-speed model gives max. 1500SPM,
The high-speed model gives max. 1200SPM,
Normal speed model gives max. 1000SPM,
Lower speed model gives max.850SPM.
Q: Do I need the Elite model or economy model?
A: Think: How much would you pay for a machine? What we offer is what you need!
