Best Metal Spinning Machine Price for Air conditioner

Product Description

PRODUCT INTRODUCTION: 1. Bend-arm (C-axis) by electric. Clamp die by hydraulic, Pressure die by hydraulic.
2. Carriage (Y-axis) by servo motor. Collet (B-axis) : rotation by servo motor, grip by hydraulic.
3. Anticipated mandrel retraction unit. Standing pedestal, serves emergency stop and remote control.
4. Water-cooling system. Diagnosis error immediately.
5. Foot pedal for safe start.
6. It is fully automatic pipe bender, with PC control system (more advanced than PLC), two servo for rotary, feeding.
7. Touch screen panel display English, have different bending degree prefabricate, dialogue operation, can choose manual, semi-automatic and full automatic operation manual, portable pedal switch with start and emergency stop function. Multi axles working simultaneously.
8. Bending pipe - Automatic. Rotating pipe - Automatic. Feeding pipe - Automatic.
9. One key back up of programs for USB or disk storage or through INTERNET. Management and storage of bend data and tools is done in standard text files on the hard disk of the control PC. In case of requirement it is also possible to integrate the PC into bending machine. Therefore an Ethernet adapter is included. The number of tools and products is practically unlimited. Product and tool files can easily be edited (also on a separate PC) and printed out.
10. Security code for the protection the data setting and selected operation features.
11. To access to the history bending setting data to the facilitate study of malfunction with one set of tooling.
12. All the parts of hydraulic system, control system, driver system and display system are imported from famous brand, with high accuracy, high efficient, suitable for mass production.
13. CNC fully auto, have cubical space bending equipment, loading the whole bending process is automatic.
14. The electric pipe bender is convenient operation, stable performance and high safety factor. The machine is the ideal choice for the pipe processing.
15. PC assorted with touch screen display, capable of 3D bending simulation, 3D preview and collision prevention.
16. CE, ISO9001 Certification.
Technical parameter:

Model	TBM15-R(L)1(2)	BM20-R(L)1(2)	BM30	BM35
Max O.D X thickness	Φ15X 1.5mm Copper/ aluminum	Φ20X 2.0mm Copper/ aluminum	Φ32X 3.0mm (Copper/aluminum) Φ26X 2.5mm (iron/steel)	Φ38X 3.0mm (Copper/aluminum) Φ32X 2.5mm (iron/steel)
Max bending radius	R60	R80	R150	R150
Min bending radius	R10	R10	R15	R15
Max coil length	1800mm (can be lengthened)	1800mm (can be lengthened)	2600mm (can be lengthened)	2600mm (can be lengthened)
Journey of beeling feeding axis	0-1200mm	0-1200mm	0-1800mm	0-1800mm
Speed of beeling feeding axis	0-1200mm/s	0-1200mm/s	0-1800mm/s	0-1800mm/s
Precision of beeling feeding axis	±0.05mm	±0.05mm	±0.1mm	±0.1mm
Angle of spatial rotating axis	0±360°	0±360°	0±360°	0±360°
Speed of spatial rotating axis	0-500°/s	0-500°/s	0-150°/s	0-150°/s
Precision of spatial rotating axis	±0.05°	±0.05°	±0.1°	±0.1°
Angle of bending axis	0-200°	0-200°	0-190°	0-190°
Speed of bending axis	0±360°/s	0±360°/s	0±360°/s	0±360°/s
Precision of bending axis	±0.05°	±0.05°	±0.05°	±0.05°
Max bending speed	2.5s/bend	3s/bend	4 s/bend	5 s/bend
Power supply	Three-phase four-wire 380V±10% /50Hz
Hydraulic motor power	-	-	3.75kw	3.75kw
Air pressure	0.4-0.6Mpa	0.4-0.6Mpa	7Mpa	7Mpa
Total power	1.8kw	1.8kw	4.2kw	5.7kw

---
