Advanced Efficient Dual-Spindle Gang Type CNC Lathe Machine

Product Description

Product Description

1. Dual-Spindle Design for Enhanced Productivity
The double-spindle design allows simultaneous machining on both spindles, improving efficiency and reducing cycle times. This feature is ideal for high-volume production and operations requiring dual setups.
2. Compact Gang Tooling for Speed and Precision
Equipped with a gang tooling system, this CNC lathe minimizes tool change times, ensuring faster processing and higher precision, particularly for small to medium-sized components.
3. Optimized for Versatile Turning Operations
With a swing over bed diameter of 400mm and swing over carriage diameter of 180mm, this machine is capable of handling a wide range of workpiece sizes, making it suitable for diverse industries like automotive, aerospace, and electronics.
4. Double 90° Vertical Carriages for Rigidity and Stability
The double 90° vertical carriage structure enhances rigidity and stability during operation, reducing vibration and improving machining accuracy, even during heavy-duty cutting tasks.
5. Precision Components from Leading Manufacturers
The lathe features high-quality components sourced from Taiwan, Japan, and Germany, ensuring exceptional reliability, durability, and precision for long-term, consistent performance.
6. Compact Design for Space-Efficient Production
This gang tooling CNC lathe is designed with a compact footprint, making it ideal for workshops or factories where floor space is limited, without compromising on machining capabilities.
7. Cost-Effective Solution for High-Volume Production
With its dual-spindle setup, gang tooling system, and robust construction, this machine is a cost-effective choice for manufacturers seeking to increase production capacity and reduce operational costs.
Product Parameters

Machining Capacity	Swing over bed	mm	Ф400
	Swing over carriage	mm	Ф180
	Max turning dia	mm	-
Spindle	Spindle nose	-	A2-5
	Spindle bore	mm	Ф56
	Max bar material size	mm	Ф46
	Spindle motor power	kw	11
	Collet chuck size	mm	120
	Spindle speed	rpm	4500
Sub-spindle	Sub-spindle nose	-	A2-5
	Sub-spindle bore	mm	Ф56
	Max bar material size	mm	Ф46
	Sub-spindle motor power	kw	11
	Collet chuck size	inch	120
	Sub-spindle speed	rpm	4500
Axes specs	Axes travel	mm	Z1/Z2450 X1/X2900
	Axes fast moving	m/min	Z1/Z224 X1/X222
	Repeatable positioning accuracy	mm	X1/X20.003 Z1/Z20.005
Tool 1	Gang tool	-	Gang tool
	Tool holder size	mm	20*20
Tool 2	Gang tool		Gang tool
	Tool holder size	mm	20*20
Other specs	Programming		ISO standard
	Cooling motor	w	370
Measurements	Dimension		around 2700*1550*1900
	Weight	kg	around 3200

Certifications
We have our own independent R&D and design team and have applied for a number of technical patents. From high-precision spindles to bed bodies to external sheet metal, the R&D and design department designs and the production department implements, giving us full control over design and production autonomy, making it more flexible and changeable.
Company Profile
Yuhuan Jiaou CNC Machine Tool Manufacturing Co., Ltd. is located in Bingang Industrial City, Shamen Town, Yuhuan City. Our company is a technology-based enterprise, specializing in the R&D, production and sales of CNC machine tools, and has a professional technical and sales service team who has long been engaged in the design and development of CNC machine tools, constantly innovating and advancing with the times. The precision CNC lathes designed for the metal working, including gang type, turret type, mill-turn compound type, can easily handle complex, precise, small-batch, and multi-variety part processing problems, and provide customers with targeted and efficient metal cutting solutions, creating more possibilities for their intelligent and automated production processing.
Equipped with a complete quality testing system and sophisticated testing instruments, our company has passed the ISO9001 system certification to ensure that we provide customers with high-quality equipment and fast after-sales service.
We adhere to the business philosophy of "Detail first, customer first, and creating maximum value for customers", and always implements the quality guideline of "Quality first, continuous improvement". We provide full-service from pre-sales to after-sales, from products to designs, and wholeheartedly commit to providing customers with thoughtful, advanced, high-quality, cost-effective equipment.
Creating the greatest value for you is of most significance for Jiaou's efforts!
Yuhuan JIAOU CNC has multiple production workshops, from bed component blank processing, optical and mechanical assembly, installation and debugging, sheet metal laser cutting and bending, external protective sheet metal spraying, etc., all of which are independently produced and processed.
Packaging & Shipping
FAQ
Q: What's the availability of spare parts?
A: We maintain a comprehensive stock of spare parts with quick delivery options.
Q: What CNC control system does it use?
A: Our machines can be equipped with different brands of CNC control systems, such as FANUC, SIEMENS, SYNTEC, KND, GSK, etc.
Q: Do you provide operator training?
A: Yes. We welcome your engineers or operators to have operator training at our site. And we are able to provide online technical support as well.
Q: What's the lead time for delivery?
A: Faster delievery time. 10-20 days for our standard regular machines, the delivery time of customized machine need to be negotiated.
Q: Is customization available?
A: Yes. We have rich experience in custom processing and can provide flexible customization services from bed to processing parameters to appearance.

---
