| Performance Characteristics | O.S. | CE 6.0, multi-language | |
| CPU | Single core 1GHZ | ||
| Display | 2.8 inch QVGA with backlight TFT Touch screen LCD | ||
| Memory | ROM | 128MB | |
| RAM | 256MB | ||
| Barcode Scanner | 1D Laser | Decode Capability | Code 39; Codabar; Code 128; Discrete 2 of 5; IATA 2 of 5; Interleaved 2 of 5; Code 93; UPC A; UPC E0; EAN 8; EAN 13; MSI; EAN 128; UPC E1; Trioptic Code 39; Bookland EAN; Coupon Code; RSS-Limited; RSS-14; RSS-Expanded. |
| 2D CMOS (Optional) | Decode Capability | 1D Symbologies: UPC / EAN, Bookland EAN, UCC Coupon Code, ESSN EAN, CODE 39, CODE 128, GS1-128, ISBT 128, Trioptic Code 39, CODABAR, MSI, Interleaved 2/5, Discrete 2/5, Chinese2/5, Korean3/5, Matrix 2/5, CODE 32, CODE 93, CODE 11, Inverse 1D, GS1 DataBar, Composite Codes. 2D Symbologies: PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse, MaxiCode, QR Code, Aztec, Aztec Inverse. Postal Codes: U.S. Postnet, U.S. Planet, U.K. Postal, Japan Postal, Australian Postal, Netherlands KIX Code, USPS 4CB / One Code / Intelligent Mail, UPU FICS Postal. | |
| Radio Communication | WiFi (WLAN) | Supports 802.11 b/g/n, the maximum rate of 65 Mbps Supports 802.11 I: AES, TKIP, WEP, WPA, WPA2 Supports BT coexist, fast seamless roaming | |
| WWAN | Built-in wireless network communication GSM / GPRS module Frequency Range: GSM850 / 900 / 1800 / 1900 MHz GPRS multi-slot Class 10: DL 85.6 kbps / UL 42.8 kbps GPRS multi-slot Class 8: DL 85.6 kbps / UL 21.4 kbps | ||
| BT | BT V2.1+EDR | ||
| Options | Camera | 5.0M mega pixels with flash and automatic focus | |
| RFID | compatible with HF RFID | ||
| Power | Main Battery | 3.8V 4500mAh rechargeable lithium battery, which can work for 12 hours or above (depending on environment) | |
| User Environment | Operating Temperature | -10°C to +50°C | |
| Storage Temperature | -20°C to +60°C | ||
| Humidity | 5%-95% (non-condensing) | ||
| Drop Durability | 4ft. / 1.2m multiple drops to concrete across the operating temperature range | ||
| Peripherals and Accessories | Expansion Card Slot | Micro SD/TF (max 32G) | |
| Physical Interface | Mini USB x 1, 3.5mm audio interface x 1, DC Jack x 1, POGO PIN interface x 1 | ||
| Charging Dock | Optional single slot dock: supports to charge one unit of device and one spare battery simultaneously | ||
| Printers | Can connect with the serial port printer, BT printer | ||
| Other Accessories | Standard equipped with handwritten pen, wrist strap; Optional with carrying pouch | ||
| Regulatory | Sealing | IP54 1.2M drop | |
| Product Certification | CCC, CE, FCC | ||
| Laser Safety | IEC Class 2 / Class II, in accordance with IEC60825-1 / EN60825-1 | ||
| Warranty | 12 months (except the accessories) | ||
