Single Fiber Single Mode 20km 1.25g LC Port Tx 1310nm Rx 1550nm SFP Module

Product Description

SFP 1.25G 20km 1310nm SFP Module Duplex LC DDM
Features:
1. Industry standard Small Form Pluggable (SFP) package.
2. Digital diagnostic monitor interface compliant with SFF-8472.
3. 1310nm FP Laser and a PIN receiver.
4. Very low EMI and excellent ESD protection.
5. Power consumption less than 1.0W.
6. Hot-pluggable capability.
Advantages:
1. The transceiver is a low power, high performance, cost effective module supporting data-rate up to 1.25Gbps 20km transmission distance.
2. The low jitter and high sensitivity are extinguished features with 1310nm FP laser and PIN/TIA receiver.
3. The transceiver incorporates TX_DIS control, TX-FAULT, and RX_LOS monitor functions. The devices are Class I laser safety compliant.

Parameter	Symbol	Min	Max	Unit
Storage Temperature	TSTG	-40	+85	ºC
Ambient Operating Temperature	TA	0	70	ºC
Optical Rise/Fall Time	Tr /Tf	-	0.26	ns
Eye Diagram	IEEE 802.3z and ANSI Fibre Channel Compliant
Power Supply Current	Icc	-	200	mA
Extinction Ratio	ER	9	13	dB
Sensitivity	S	-	-23	dBm
Warning	assert>-34dBm,de-assert<-26dBm

Q&A
Q: What kinds of custom choices are offered in YXFiber?
A: As for customized transceivers, YXFiber offers regular custom choices such as compatibility, transmission distance, operating temperature, label pattern, label colors and etc. What's more, YXFiber welcomes any inquiry for customized products and solutions for all need and specifications.
Q: Why should I trust YXFiber compatible transceivers?
A: Besides the price advantage, we have compared to branded transceivers, YXFiber compatible transceivers also maintain the same performance and reliability. To satisfy our customers' needs of high performance, all of our transceivers are tested multiple times in mainstream original brand switches in our test center before shipped out.
Q: Can we use APC connectors on this?
A: Hi, as the default type is UPC, so it's only can be connected with UPC connectors. Thanks
Q: Once I place an order for my transceivers, how long will it take to receive them?
A: Normally you can receive the goods within 7 workdays
Q: Will using compatible optics in my equipment negatively affect my manufacturer's warranty?
A: No. Network equipment manufacturers do not require that you use only name-brand optics. In fact, when a product fault or defect occurs in the network, and the fault or defect is not attributable to the use of third-party optics, they will continue to provide support for the affected product under warranty or covered by their support program.

---
