20FT/40FT/45FT/60FT Roll Mafi Trailer, Roll Trailer for Heavy Static Goods and Materials in The Maritime Shipping Industry

Product Details

Product Description

Product Description
Terminal Use Purpose Gooseneck 20FT/40FT/45FT/60FT Roll Mafi Trailer

The 45ft Mafi trailer with Wood Floor

The 30ft/40ft/45ft Mafi trailer with Steel Floor
The Mafi trailers loading on board
RO-RO Trailer is designed for moving container within in container terminal and transporting overheight cargo inside Ro-Ro vessel. It can be equipped with fixed or detachable gooseneck per your operational situation. Wooden floor and lashing are also available on request.
Specifications:

Dimensions	15390*2600*1680 mm
Weight	Loading capacity	60-80 tons
	Tare weight	10 tons
	G.V.W.R.	70-90 tons
Frame & Structure	Platform Length	12350 mm
	Platform Height	820mm
	Ground Clearance	320mm
	Main Beam	Q345, Height 500mm
	Platform	4.5 mm, wooden plate
	Painting	Shot blast at Standard SA 2.5 prior to application of primer polyurethane top coat.
Running gear	Axle	140*140
	Tire	Steel reinforced solid rubber, 22"x16"x16"*8pcs
	King pin	2'' and 3.5 welded or bolted type
Accessories	Lashing Ring * 2 pcs per side
Color	Customized

---
