P0.9/1.25/1.53/1.66/1.86/2.5 Indoor Ultra Thin Low Power Consumption Fine Pitch Shop Advertising Front Service Magnetic Module LED Video Wall

US$157.00-270.00 1 Piece (MOQ)

Basic Info.

Model NO.

P2.5

Pixel Pitch

2.5mm

Pixel Configuration

1R,1G,1B

Pixel Density

160000

Scanning Mode

1/32 Scan

Display Type

LED Video Display

Application

Stage Performance, Advertising, Shopping Guide

IP Rating

IP31

Certification

CE, RoHS, CCC

Cabinet Size

640mm*480mm

Cabinet Material

Die Cast Cabinet

Refresh Rate

3840Hz/S

Brightness

1200CD/Sqm

Transport Package

Wood Box

Origin

Shenzhen China

HS Code

8528591090

Production Capacity

5000sqm/Year

Product Description

INDOOR FIXED LED DISPLAY SPECIFICATION
01	PIXEL PITCH	1.25MM	1.538MM	1.667MM	1.86MM	2.5MM	3MM	4MM	5MM	6MM
02	MODULE SIZE	320*160MM	320*160MM	320*160MM	320*160MM	320*160MM	192*192MM	256*128MM	320*160MM	192*192MM
03	MODULE RESOLUTION	256x128	208x104	192x96	172x86	128*64	64*64	64*32	64*32	32*32
04	PIXEL DENSITY	640000/m²	422754/m²	360000/m²	289051/m²	160000/m²	111100/m²	62500/m²	40000/m²	27777/m²
05	LED LAMP	SMD1010	SMD1212	SMD1212	SMD1515	SMD1515	SMD2121	SMD2121	SMD3528	SMD3528
06	THE OPTIMUM VIEWING DISTANCE	1.2~20M	1.5~20M	1.6~20M	1.8~20M	2.5~20M	3~50M	4~50M	5~50M	6~20M
07	MAXIMUM POWER CONSUMPTION	2500W/m²	2000W/m²	1700W/m²	1700W/m²	1250W/m²	850W/m²	500W/m²	600W/m²	850W/m²
08	AVERAGE POWER CONSUMPTION	600W/m²	500W/m²	400W/m²	400W/m²	300W/m²	200W/m²	120W/m²	150W/m²	200W/m²
09	STANDARD CABINET SIZE	640x480MM	640x480MM	640x480MM	640x480MM	640x480MM	768*768MM	768*768MM	960*800MM	768*768MM
10	CABINET RESOLUTION	512x 384	416x312	384*288	344*258	256*192	256*256	192*192	192*160	128*128
11	CABINET WEIGHT	15KG	15KG	15KG	15KG	15KG	20KG	20KG	26KG	20KG
12	DRIVING METHOD	1/64 SCAN	1/52 SCAN	1/54 SCAN	1/43 SCAN	1/32 SCAN	1/32 SCAN	1/32 SCAN	1/16 SCAN	1/8 SCAN
13	BRIGHTNESS (CD/m²)	≥1000CD/m²	≥1000CD/m²	≥1000CD/m²	≥1200CD/m²	≥1200CD/m²	≥1500CD/m²	≥1500CD/m²	≥1500CD/m²	≥1500CD/m²
14	APPLICATION	INDOOR
15	PIXEL COMPOSITION	1R1G1B
16	THE OPTIMUM VIEWING ANGLE	140°/120°
17	FREQUENCY	50 ~ 60Hz
18	REFRESH RATE	3840Hz/s
19	BRIGHTNESS ADJUSTMENT	0~100% 256 LEVELS
20	GREYSCALE	16BITS AFTER CORRECTION
21	OPERATING TEMPERATURE	-20ºC-60ºC
22	OPERATING VOLTAGE	220V /110V
23	OPERATING HUMIDITY	10 ~ 90%RH NON-CONDENSING
24	COLOR TEMPERATURE	6,500K ~ 9,500K ADJUSTABLE (6,500K DEFAULT)
25	IP RATING (FRONT/REAR)	IP31
26	LIFETIME	≥100,000H

Installation Instructions
Company Profile

Our Advantages

Packaging & Shipping
