| Mountings | Specifications | Unit | CSD-250M |
| Ability | Table Dimensions | mm | 460×200 |
| Maximum forward and backward movement | mm | 540 |
| Maximum left-right movement | mm | 260 |
| Distance between spindle center and work surface | mm | 470 |
| Maximum bearing weight of working table | kgs | 100 |
| Work Table | Table T-slots | mm×N | 14×1 |
| Table speed | m/min | 7-25 |
| Front and rear handwheel feed | a check | mm | 0.02 |
| a round | mm | 4 |
| Auto-supplying from front to back | mm | / |
| High speed moving from frong toback | 50HZ | m/min | / |
| 60HZ | m/min | / |
| Grinding Wheel | Grinding Wheel Size | mm | Φ205×6-20×31.75 |
| Speed of mainshaft | 50HZ | R.P.M | 2850 |
| 60HZ | R.P.M | 3360 |
| Upper and lower mechanism | Up& down handwheel feed | a check | mm | 0.01 |
| a turing round | mm | 2 |
| Auto-supplying volumn | mm | / |
| High-speed mouing dimension from up to down | mm/min | / |
| Motor | Spindle motor | H×P | 2×2 |
| Drive motor up and down | H×P | / |
| Drive motor up and down | H×P | / |
| Vacuum motor | H×P | 3/4×2 |
| Dust catching motor | H×P | 1/8×2 |
| Back and front driving motor | H×P | / |
| Machine Size | Mechanical height | mm | 1775 |
| Occupied area | mm | 1800×1400 |
| Net weight | kgs | 1100 |
| Gross Weight | kgs | 1300 |
