| US$90,000.00-100,000.00 | 1 Piece (MOQ) |
| Description | Unit | Parameter value | |
| Outline dimension | mm | 13915mm*2530mm*4000mm | |
| Overall weight | kg | 44000 | |
| Chassis | Model | Benz Actros 4141 | |
| Max. speed | km/h | 90 | |
| Max. grade-ability | % | 40 | |
| Wheelbase | mm | 4800+1400 | |
| Tire | 385/65R22.5/315/80R22.5 | ||
| Engine | Model | / | |
| Max. power | kW | 200 | |
| Max. torque | N·m/(r/min) | 1800 | |
| Displacement | L | / | |
| Emission standard | Eruo IV | ||
| Pumping system | Theoretical output | m3/h | 180 |
| Concrete pumping pressure | MPa | 11 | |
| Theoretical pumping times | Time/min | 23~26 | |
| Delivery cylinder diameter ×stroke | mm | Φ260×2100 | |
| Max. diameter of pumping concrete | mm | ≤40 | |
| Filling height | mm | 1580 | |
| Concrete slump range | cm | 8~23 | |
| Placing boom | Reach height | m | 56 |
| Reach depth | m | 40.2 | |
| Slewingradius | m | 51 | |
| Slewing angle | ° | ±270 | |
| Stabilizer span | Longitudinal span of stabilizer | mm | 8955 |
| Transverse span of front stabilizer | mm | 7884 | |
| Transverse span of rear stabilizer | mm | 9940 | |
