Portable Ultrasound Scanner for Veterinary Use Bc5200V with 6.5MHz Rectal Probe

Product Description

Model	BC5200V
Product name	Digital wrist-top veterinary ultrasound scanner
Carton size	265*240*345mm
Volume	0.0219cmb
Net weight	1.1kg/2.4lbs
Gross weight	3.5kg/7.7lbs
Volumetric weight	4.5kg/9.9lbs
Shipment	By air

Application
1. Equine -Reproduction, Tendon & Abdominal, Cardiac, Breeding, etc.
2. Farm Animal -Reproduction imaging on Bovine, Swine, Small ruminants and other large animals
3. Small animal -Criticare, Abdominal, Cardiac, etc
Benefits
1)1.1kg ( 2.4 lbs)
2)Rechargeable Battery Life of 200 minutes
3) 5.7" LCD Display, high-brightness and high-contrast
4)100 images built-in storage
5)Freeze image switch with free hand
6)256 Frames Cine
7)USB Port for Flash Card Memory
8)8 Stages of Magnification
9)Concise Menu for Operation
10)Good Brightness for Outdoor Scanning
11)Wrist Mount and Belt-hanger( for holding probes)Available
Primary Function
1. Body marks: 1. Bovine 2. Dog 3. Equine 4. Cat 5. Cadioloy, total 22 kinds
2. Probe connector: 1PC, automatic identifying function
3. Receiving channel: >=16 digital beam former
4. Resolution: Horizontal<=2mm, Vertical<=1mm
Dead Zone: <=5mm
5. Maxim scanning depth: >=190cm(according to the probe)
6. Geometric position accuracy: Horizontal<=5%, Vertical<=5%
7. Scanning mode: B, 2B, 4B, B/M, M
Full field image with 8 lever adjustment(8 kinds Magnification)
8. Gain range: General gain continuously adjustment(0~127dB)
9. Dynamic range: 27~90dB, video adjustable
4 kinds angles /width adjustment
10. Gray: 256
11. Imaging technology: Full digital beam forming, continuously dynamic adjustment focusing, Dynamic aperture
12. Image storage: 100 frames permanent storage
13. Cine loop: 256 frames
Intelligent TGC control: Near-field and far-field adjustment
14. Imaging processing: Pre-processing (continuous dynamic focusing, dynamic aperture, dynamic filtering), post-processing (4 gamma correction), correlation processing (4 levers), Left/right, positive/negative, vertical, horizontal flip and B/W conversion, edge enhancement (4), etc.
With the image enhance the depth and the local amplification
Wire switch realize the freezing and unfreezing
15. Frame rate: 30 frames/second
16. Measurement:
Normal measurement: Distance, Perimeter, area (tracing method, ellipse method), volume, etc.
OB measurement: Cattle, dogs, horses, cats, goats, camels and sheep and pre-gestational age birth
Heart of conventional measurements: Depth, slope, heart rate, period
17. Report: OB report
18. Character Tags: Name, age, hospital name, and automatically display the date, time, probe type, probe frequency, frame related to the number of the focus number, gain, dynamic range, etc
19. Battery: (2400mAh), Large capacity lithium Battery, more than 200 minutes work
20. Weight of main unit: 1.1Kg
21. Interface language: English
22. Puncture and guide functionality(Puncture and guide wire 2 can be calibrated, angel and position are adjustable)
23. Positioning line
24. High-speed USB-A port: Supporting Large-capacity disk and mouse U
High-speed USB-B port: Could transfer image('case report software V3.1'software)
25. Dual-mode output: PAL/NTSC
26. Print Output: Optional Video Recorder
27. Other Optional: Battery, battery Charger, apparatus, strap, bracket

---
