| US$4,000.00-6,000.00 | 1 Set (MOQ) |
| Room outside size: | 6950*4000*3470mm | |
| Room inside size: | 6850*3900*2650mm | |
| Panels: | Wall panels:50mm thick antiflaming EPS panel,with 0.4mm thick steel skin, With tongue & groove style, anti-flame and heat-insulation; Roof panel: galvanized steel panels. | |
| Main door: | 3-fold main doors,total 3000*2500mm(W*H),with safety glass, with handles and high-pressure safety lock, rubber strips. | |
| Side door: | 1 unit 700*1800mm(W*H), with safety glass windows, aluminum alloy frame, with handle,safety lock and rubber strips. | |
| Basement: | Total height is 300mm with grills,embossed plates, and bottom supports; Grills: 2 rows, material: 30*4mm thick; Embossed plate:2mm thick plate with supports, 3 rows on floor; Ramp:Two sets of hard strength ramps, size:1600*650*260mm; | |
| Air fans: | Intake Fan: | 2*4kw;20000m³/h. |
| Exhaust Fan: | 1*7.5kw; 18000m³/h. | |
| Cabinets: | Bottom cabinet for the fans, size:2700*1100*1290mm; Upper cabinet for heating exchanger, size:1700*1100*1290mm; | |
| Electric damper: | TF16-230, 20N.m; Install on the cabinet to control the inner air door. | |
| Air ducts: | Exhaust air ducts: Trapezoidal duct: 1pc; Elbow 90°duct:1pc; Straight ducts:2pcs, size:700*700*900mm; Inlet air duct: upper bend air duct*1pc; All the material thickness is 0.8mm. | |
Filtering system: | Pre-filter, filtering rate>83%,can capture granules larger than 10μm; Ceiling filter,filtering rate>97%, can capture granules bigger than 4μm; Floor filter, filtering rate>70%. | |
Heating System: | Diesel burner heating, Italy Riello G20 oil burner. Heating productivity: 200000 Kcal/h, 0.8mm thick steel heating exchanger, with anti-explosion hole for protection, max working temperature is 80ºC. | |
| Lighting system: | Ceiling lights: 8units*3pcs=24pcs, powder-coated light box. Wall lights:6units*3pcs=18pcs,vertically set,powder-coated light box. | |
| Controlling system: | Intelligent control:power switch,spray/baking switch,light switch,emergency stop, electric damper button. | |
| Power total: | About 16kw, voltage: 380V/50HZ/3P | |
