Fertilizer Vibrating Screen Equipment Sieving Machinery (PXZS)

Product Description

About Us Headquartered in Xinxiang City, Henan Province, China, domestic well-known screening and conveying equipment city, PK Machinery has enjoyed more than 50 steady years of successful growth, and now it has been widely acknowledged as a trustworthy and professional manufacturer in the field of bulk material handling equipment, including vibrating screen, vibrating feeder, belt conveyor, bucket elevator, screw conveyor, scraper chain conveyor and associated spare parts in complete specifications.

Product Description Fertilizer Vibrating Screen Equipment Sieving Machinery (PXZS)
NPK Fertilizer Seiving Machinery is a new screening device developed by introducing advanced technology abroad based on producing more screening machineries.
There are following advantages: Reasonal design, stable running, full-sealed construction, no dust pollution, plugged hole proof, sticking proof etc.
Especially NPK Fertilizer Seiving Machinery is more obvious to carbamide screening with strong hygroscopicity, big viscosity, easy plugged hole and sticking.
Reduce validly base dyamic load for adopting rotary principle.
Application
NPK Fertilizer Seiving Machinery is a new screening device which is developed mainly aiming at screening of bulky grain carbamide, also used widely for screening operation in chemical industry, grain production, fire-proof materials, buliding materials etc.
Advantages

No vertical vibrating and long span life sieve mesh(from 6 to 12 months).

Sieve mesh anti clogging clearing device is set up on each layer of mesh. The unplugged hole of mesh prolongs runnig period. Sieve classifier constantly clears the sieve mesh under working condition.

Adopting rotary principle improves obviously materials distribution, increase effective utilization of screen deck, finally increase the screen efficiency and reduce powder content of finished materials.

Full-sealed construction and no dust pollution improve working circumstance of operation sales person.

Reduce dyamic load 3 to 5 times to base.

Product Parameters
Technical Parameters

No. of Deck	Model	Screen Surface Size (W*L)	Screen Box Motion Stroke	Motor
				Power	Rotate Speed
		(mm)	(mm)	(kw)	(rpm)
1-3	PXZS 1224	1200*2400	75-90	5.5	1450
	PXZS 1230	1200*3000		5.5	1450
	PXZS 1236	1200*3600		5.5	1450
	PXZS 1524	1500*2400		5.5	1450
	PXZS 1530	1500*3000		5.5	1450
	PXZS 1536	1500*3600		5.5	1450
	PXZS 1824	1800*2400		7.5	750
	PXZS 1830	1800*3000		7.5	750
	PXZS 1836	1800*3600		7.5	750
	PXZS 1842	1800*4200		7.5	750
	PXZS 2036	2000*3600		7.5	750

Selection condition

Material to be processed.

Granule size of the materials(Mesh size).

Moisture content ,density.

Granule size proportion if possible to get,the number of lays.

Capacity (tons or kg per hour ).

Local power supply(voltage and frequency).

---
