Blend Polyol Used in Panel PU Foam for Insulation

Product Description

DESCRIPTION
SDB23D is a kind of blend polyol used for discontinuous sandwich panel designed with HCFC-141B system. SDB23D type sandwich panel is a kind of thermal insulation panel which used for cold storage, using rigid PU foam as core layer, metal material or other materials as the surface of the panels. The sandwich panel can cover different kinds of materials such as color steel, aluminum alloy, galvanized steel, stainless steel and aluminum plated zinc plat. The SDB23D type foam has the following characteristics:
The production process is relatively simple, less equipment investment
The bonding of rigid PU foam and steel material is very good.
Good flame retardant performance, the index of oxygen can reach up 24%.
Easy install, cold storage construction is very convenient.
Cold storage panel can be used repeatedly.
TYPICAL PHYSICAL PROPERTIES

Physical Properities	Metric	Value	Test Method
Core Density	kg/m3	32--42	GB/T 6343-2009
Initial Thermal Conductivity	W/(m·K)	<0.024	GB/T 10294-2008
Flammability Properties	level	2	QB/T 3806
Compressive Strength	KPa	≥150	GB/T 8813
Water Absorption	%	≤4	GB/T 8810
Dimensional Stability	70ºC 48h	≤4	GB/T 8811
	-30ºC 48h	≤4	GB/T 8811

Importance: The above mentioned are typical test values, and the specific data may vary slightly due to environmental conditions.For our products, the data are not legally binding.
Other unmentioned matters and TDS&MSDS.Please visit our official website shundapu.en.made-in-china.com
Or please contact us for information:

---
