| Model No. | FC-77EB | FC-94EB |
| Size | 77inch | 94inch |
| Dimension | 1890*787*120mm | 2219*919*120mm |
| Main Screen | 1209.6*680.4mm | 1428.48*803.52mm |
| Sub-Screen | 605(H)340(V)mm | 714(H)*402(V)mm |
| Voltage | 110-240V(AC) 50/60Hz | |
| Power Consumption | ≤160W(without oPS) | |
| Main Screen size | 55 inch IFP | 65 inch IFP |
| Panel | A Grade 4K LCD Screen | |
| Resolution | 3840*2160mm(H*V) | |
| Ratio | 16:09 | |
| Contrast | 4000:01:00 | |
| Brightness | 400cd/m2 | |
| System | Android 110 embedded system | |
| Processor | Cortex A53*4,quad cores ,1.5GHz | |
| OPs PC | Intel i3/i5/i7(Optional) : Windows10/11(Optional) | |
| Touch | IR touch, 20 points, HID free drive; Touch Response<6ms | |
| Speaker | 2*15W/8 | |
| For Students | - Provide highly interactive learning experiences to encourage student engagement and focus.<br>- Support the display and sharing of various learning resources such as videos, images, documents, etc., to meet the needs of different subjects.<br>- Offer online testing and assessment functions to help students reinforce knowledge and assess learning progress. |
| For Teachers | - Provide rich teaching tools and resources to support classroom interaction and instructional design.<br>- Allow teachers to create and display courseware in real-time, as well as annotate and explain in real-time during class.<br>- Provide teaching management functions to help teachers manage course content, student performance, etc. |
| For Parents | - Provide communication channels between parents, schools, and teachers to understand their children's learning progress and performance.<br>- Allow parents to view students' course materials, homework, and grades to better support their children's learning. |
| For Educational Institutions | - Support educational institutions in curriculum planning, resource management, and teaching assessment.<br>- Provide multi-touch and real-time collaboration functions to support collaboration and communication within educational institution teams. |
| For Training Institutions | - Provide customized training courses and teaching plans to meet the training needs of different industries and fields.<br>- Support remote teaching and online learning to enable training institutions to reach a broader audience of learners. |
| For Learners of Different Age Groups | - Provide corresponding learning content and teaching methods for learners of different age groups, such as interactive games for children and multimedia courseware for teenagers.<br>- Support personalized learning paths and recommend learning resources based on learners' abilities and interests. |
| School Classrooms | - Primary teaching tools for class instruction.<br>- Support teachers in student interaction and resource display. |
| Corporate Meeting Rooms | - Display meeting agendas and data analysis.<br>- Facilitate team discussions and decision support.<br>- Enhance meeting efficiency and participation. |
| Training Institutions | - Course training and lecture presentations.<br>- Knowledge sharing and support for remote training and online learning. |
| Hospital Consultation Rooms | - Facilitate communication between doctors and patients.<br>- Display health information to improve diagnosis efficiency and patient experience. |
| Library Reading Rooms | - Display learning resources and academic discussions.<br>- Support student self-study and enrich the learning environment and resources. |
| Commercial Exhibition Halls | - Product displays and interactive experiences.<br>- Sales presentations to enhance brand image and customer experience. |
| Public Transit Stations | - Information dissemination and navigation guidance.<br>- Advertising to provide convenient services and information delivery. |
| Hotel Lobbies | - Customer service and event promotion.<br>- Tourism recommendations to improve customer satisfaction and hotel image. |
| Government Offices | - Discussion of meeting agendas and interpreting policies.<br>- Public information dissemination to enhance governmental efficiency and transparency. |
| Home Entertainment Spaces | - Home theaters and interactive gaming.<br>- Organizing family activities to enrich home entertainment options and experiences. |
| * Panel System | ² Dual system structure: Android and Windows system. ² With fast switching between dual systems. ² Built-in Android 13.0 system, with high performance CPU CortexA55, 4 cores, 1.9Ghz; ² Android system 15 languages: Chinese, Traditional Chinese, English, Portuguese, Korean, Japanese, Italian, Russian, French, German, Spanish, Arabic, Thai, Vietnamese, Polish. |
| *Unique structure | ² The front sliding lockable design on front bezel can better protect the equipment. ² It's with 4mm physical tempered anti-riot/anti-glare glass, safe and eye-protecting. ² Infrared touch sensors are embedded in the frames, with waterproof and dust-proof design. |
| *Featured functions | ² Widely used for education, conference and training; ² It Support 20 points touch, 10 people can write at the same time. ² There are 4 physical buttons, support one-key to quick start-up: One-click for Energy saving, Casting screen, Recording screen and Anti-blue light. ² With 3-in-1 switch on/off design: One button can be with functions of Power-On/Off, Energy Saving/Wake-up, PC On/Off. ² 3-finger to call the switch button quickly from any area. ² 5-finger to standby and wake-up screen quickly. ² 5-finger gesture to auto-identify writing and eraser. ² Network support: wired network and wireless WIFI, 2.4G +5G, Bluetooth 5.0. ² Support multiple signal source selection, sleep timing, and shutdown memory channel. ² Support automatic identification of signal sources and switching channels. ² Support TV remote function, child lock, U-disk lock, App lock. ² Support U-disk follow, automatic identification and classification of U disk content. ² 4K UI takes better eye-sight display effects. | |
| * Practical software | ² QR code scan & share, ² Screen share (4 split;Phone & PC), ² Voting, ² Screen recorder, ² Fast file transfer, ² Scroll down half screen, ² Thick & Thin pen switch, ² Hardware self-check, | ² Full-channel annotation and screen capture, ² The dual-screen split for different apps operation. ² 4K Whiteboard software, support: * to insert table and multi-graph * to automatic recognize written characters and graphics; * to insert multiple media files and other sources; * to write and erase in 4 split screens . ² File management, Office, Browser etc... |
Windows System (Optional OPS PC) | CPU: I5-4th Generation (I3/I5/ I5 as optional) | |
| Storage: 4G; 128GSSD (4/8/ 16G +128/256/512/1T G as optional) | ||
| Intel integrated HD graphics | ||
| WIFI: 802.11b/g/ n | ||
| Windows: Pre-install Win 10 Pro | ||
Touch | Touch Technology | IR touch; 20 points; HIB Free drive |
| Touch Items | Pen, finger, any opaque objects | |
| Response Speed | ≤ 8ms | |
| Operation System | Support Windows7/10, Android, Mac OS, Linux | |
| Speakers | Power | 15W*2 / 8Ω |
I/O Ports | Input Ports (Rear) | HDMI*1, LAN(RJ45)* 1 , AV in(mini)*2 |
| Output Ports(Rear) | SPDIF* 1, Earphone*1, AV OUT(mini) | |
| Other Ports(Rear) | USB 3.0* 1, USB2.0* 1, RS232*1 , Touch USB* 1, OPS Slots*1 | |
| Front Ports | USB*3( Full function), HDMI in*1, Touch USB* 1, Type-C* 1 | |
| OPS Ports (Optional) | USB2.0, USB3.0, VGA, HDMI-out, RJ45,WIFI,AUDIO OUT, MIC, POWER | |
| Function Buttons | 8 buttons on front bezel: Power/Eco, Source, Menu, Home, PC, Anti blue light, Screen record, Screen share | |
| Working Environment | Working temperature | 0ºC-40ºC |
| Storage temperature | - 20ºC~60ºC | |
| Working humidity | 10%-90% non-condensing | |
| Accessories | Power cable *1 pcs; Remote Controller*1 pcs; Touch Pen*1 pcs; QC card*1 pcs ; Warranty card*1 pcs; Wall mount brackets*1 pcs; | |
