| OPERATING WEIGHT | 3500KG |
| RATED OPERATIONG CAPACITY | 1050KG |
| TIPPING LOAD | 2100kgs |
| ENGINE TYPE | DIESEL, 4CYCLE, WATER COOLED |
| ENGINE MAKE & MODEL | DEUTZ 226B |
| ENGINE POWER | 75HP |
| ENGINE DISPLACEMENT | 3107CC |
| TRACK WIDTH | 1500mm |
| WIDTH WITH BUCKET | 1880mm |
| HEIGHT AT MAXIMUM EXTENSION | 4070mm |
| MAXIMUM REACH | 700mm |
| TRAVEL SPEED | 8/16km/h (2-speed) |
| FUEL TANK VOLUME | 90L |
| WORK FLOW | 75/115L/Min (high-flow) |
| LIFT HEIGHT (HINGE PIN) | 3150mm |
| GRADE ABILITY | 20° |
| DUMPING HEIGHT | 2230mm |
| DUMPING ANGLE | 40 degree |
| GROUND CLEARANCE | 205mm |
| CYLINDER FOR BUCKET TILT | 2 nos. |
| WHEEL BASE | 1115 mm |
| OVERALL L*w*H mm | 3420*1740*2050 |
| Enclosed Operator Cab | STANDARD |
| HYDRAULIC CONTROL SYS. | STANDARD |
| AIR CONDITIONER | OPTIONAL |
| Original PERKINS Engine | OPTIONAL |
| Packaging Detail: | 2units in one 20 feet container, 4units in one 40 feet container |
| Delivery Detail: | 20-30days |
