Jinan CNC Router 1530 3 Axis CNC Machine MDF Cut and Engrave 4.5kw Air Cooling Spindle for Furniture for Sale in Netherlands

Product Description

CNC Router 1530 3 axis cnc machine with 4.5kw air cooling spindle

Features
1) original 4.5kw HSD air cooling spindle ,famous brand with good quality
2) Heavy duty with very strong machine stricture make the machine more stable and durable
3) high efficiency: the vacuum adsorption table with the strong power vacuum pump , whole table absorption.
4) rapid running speed: two axes are rack gear, fast speed and high efficience, The highest speed is 45mpm.
5) Intelligent control:adopting DSP control system.It is very easy to master.
Parameters

Description	Parameter
X,Y,Z Working Area	1500*3000*200mm
X,Y,Z Traveling Positioning Accuracy	±0.03/300mm
Table Surface	T-slot and Vacuum Working Table
Frame	New type thicker and bigger heavy duty welded frame and gantry
X, Y Structure	Helical Rack gear, Taiwan PMI Rail Linear Rail
Z Structure	Taiwan TBI Ball Screw, Taiwan PMI Rail Linear Rail
Spindle	4.5kw Italy HSD air cooling spindle
Spindle Speed	0-18000RPM
Drive Motors	FL118 stepper motor and Yako 2811 big driver
Inverter	5.5kw Delta Inverter
Lubrication system	Manual lubrication system
Working Voltage	AC380V, 3Ph, 50Hz (Option: 220V)
Operating System	DSP A11 Control System
Control box	Single-sided indenpended control box
Dust collector	1.5kw double pockets dust collector, (AC380V, 3Ph, 50Hz)

PS:All the working area and specifications can be customized according to your requests.
Sample & Application
1. Wood furniture industry
Doors; Cabinets; Tables; Chairs.
Wave plate, fine pattern, antique furniture, wooden door, screen, craft sash, composite gates, cupboard doors, interior doors, sofa legs, headboards and so on.
2. Advertising industry
Signage; Logo; Badges; Display board; Meeting sign board; Billboard
Advertising filed, sign making, acrylic engraving and cutting, crystal word making, blaster molding, and other advertising materials derivatives making.
3. Die industry
A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand , plastic sheeting, PVC pipe, and other non-metallic mold.
4. Artwork and Decoration
wood crafts; gift box; jewelry box
5. Others
Relief sculpture and 3D engraving and Cylindrical object.
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
*More than 95% of the timely response rate, timely response to customer questions
After-Sales Service
* Training how to install the machine, training how to use the machine.
* Engineers available to service machinery overseas.
* Use online contact methods such as skype whatsapp facebook to provide online services to customers.
Packaging & Delivery
Packaging Details
1.The innermost layer is EPE pearl cotton film package.
2.The middle layer is wrapping up with environmental protection material .
3.And the outermost layer is winding up with PE stretch film.
4.They're very environmentally friendly.
5.If you need a wooden box, we will make a wooden box.
Delivery Detail: Shipped in 25-30 working days after payment.
Company Introduction
Jinan Blue Elephant CNC Machinery, the professional cnc router and laser cutting machine manufacturer in China, include ATC CNC router, Wood CNC Router, Stone CNC Router, Metal CNC Router, EPS CNC Router, 4 Axis CNC Router, 5 Axis CNC Router, Plasma Cutting Machine, Laser Cutting and Engraving Machine and so on, which have passed the CE, SGS, ISO9001 etc. Our cnc routers are widely used for advertising, woodworking, mould, stone, metal industry.

---
