US$2,000.00-28,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Certification
ISO9001: 2000
Color
Customizable Colors
Displacement/Power
6.7/156L/Kw
Displacement Standard
Euro III
Max. Driving Speed
90km/H
Production Capacity
20 Pieces/Month
Product Description
| ITEM | UNIT | SPECIFICATION |
| Model | | HMC5141THB |
| Driving System | Chassis Brand | | FOTON DAIMLER, Left Drive |
| Chassis Model | | BJ1113VFPHG-RA |
| Fuel Type | | Diesel |
| Displacement/Power | L/KW | 6.7/156 |
| Displacement Standard | | Euro III |
| Tyre Model | | 8.25R20 |
| Axle Base | M | 5.0 |
| Quantity Of Axles | | 2 |
| Max. Driving Speed | Km/H | 90 |
| Front Wheel Base | Mm | 1900 |
| Back Wheel Base | Mm | 1800 |
| Min. Turning Radius | M | 9 |
| Pumping System | Brand Of Diesel Engine | | DEUTZ Brand |
| Diesel Engine Model | | BF6M1013-25T3R |
| Diesel Engine Power | KW | 186 |
| Driving Mode | | Hydraulic Driving |
| Oil Cylinder Inner Diameter × Stroke | Mm | Ф180×Ф125×1800 |
| Concrete Cylinder Inner Diameter × Stroke | Mm | Ф230×1800 |
| Oil Pressure Of System | MPa | 32 |
| Switch Of H-Pressure And L-Pressure | | Equipped |
| Fuel Tank Capacity | L | 290 |
| Oil Tank Capacity | L | 600 |
| Cooling Mode Of Hydraulic System | | Fan Cooling |
| Max. Theoretical Capacity | M3/H | H-Pressure | 55 |
| M3/H | L-Pressure | 100 |
| Pumping Distance (H-Pressure) | Max. Horizontal | M | 125A Pipe | 880 |
| Max. Vertical | M | 125A Pipe | 220 |
| Hopper Capacity | M3 | 0.6 |
| Feeding Height | Mm | ≤1500 |
| Concrete Slump | Cm | 14~23 |
| Max. Aggregate Diameter | Mm | Crushed Stone: 40 / Pebble: 50 |
| Valve | | S Valve |
| Water Pump For Cleaning | | Equipped |
| Concrete Pipe Cleaning Mode | | Water Cleaning |
| Water Tank Capacity | L | 400 |
| Lubrication Mode | | Automatic |
| Overall Dimension | Length (Mm)*Width (Mm)*Height (Mm) | Mm | 9195*2458*2623 |
| Full-Load Total Weight | Kg | 13500 |
HAMAC has been in this field approximate 30 years already. Weare a company who is providing
the customer with machinery ofhigh quality but reasonable price. We established branches
indifferent countries to provide the local service for our machinesWe have local office in The
Philippines, Indonesia, Peru,Ethiopia etc. You are also welcomed to visit our local office in our
country.
★ How can we guarantee quality?
HAMAC owns a strict quality control system. For all the originalparts, HAMAC will check them one
by one to ensure the qualityAfter the product is finished, we have a quality control team tocheck
them according to our quality control procedures.
★ what can you buy from us?
Construction Machinery, Engineering Machinery, ConcreteBatching Plant, Concrete Pumps, Mining
Crushing Machinery.
★ why should you buy from us not from other suppliers?
· Over decades experience in construction & mining machinery;
· Professional sales team and technical support,
· Abundant export service & logistic service,
· Several professional production bases to provide you with goodquality machine in short time.
★ what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,FCA,DAF
Accepted Payment Currency:USD,EUR,CNY.
Accepted Payment Type: T/T,L/C,Western Union,
Language Spoken:English,Chinese,Spanish,French,Russian
>>
