| Fermentation Tank / Unitank/ Storage tank /Bright tank | |||
| Liter | Size Range:75L-300HL/ US 1/2bbl-250bbl | ||
| Materials | Materials:SS304, | ||
| Surface Treatment | Inside:Mirror Polish or Passivate inside, Outside:Mirror Polish or Satin Polish, | ||
| Pressure date | Inner working pressure at:0-2bar, Inner testing pressure at:2.5bar, Jacket working pressure at:0-2bar, Jacket testing pressure at:6bar, Insulatation Materials:Polyurethane foam, Dished head top 60degree conical bottom or customized, | Outlet 4" Top dia:310mm Outlet 6" Top dia:350mm | |
| Fitting Valve | Glycol inlet Glycol outlet TC Dry Hop Port &Cap+hook+handle, CIP Spray ball-360deg.&CIP Arm with butterfly valve, Pressure Vacuum&Relief Valve Kit(safety valve), Back mount oil filled/shockproof TC Pressure Gauge, Sample Valve, Thermowell, Extra TC port for carb stone as Unitank DIN OR TC Racking Arm with butterfly valve, Dump outlet with butterfly valve, Extra manway gasket,+Clamps+Silicone Gaskets, Adjustable footpad etc, | ||
| Hop Back | Pressurized design,quick-open Materials:SS304,Sanitary built 1XAdjustable PVRV 1XHigh Quality oil filled pressure gauge 1XUpper inlet valve 1XLower outlet valve 1XPessure release ball valve 1XWedge wire false bottom | 15/20/30/40/60/75/100gallons | |
| Hop Gun Hop Torpedo | Materials:SS304,Sanitary Built 1)Use ball valves,as the flow rate of ball valve is larger than butterfly valve's; 2)Larger drain out 2.5"TC to make sure dump out easily to avoid blocking; 3)High quality filter,laser cutting version,with lock device. 4)High quality parts/gaugesalves etc,and high quality casters; 5)2XCIP rotary cip balls inside; 6)Top fixed on the filter to avoid shaking when do recirculation; 7)Heavy duty design between legs also set up brackets between legs; 8)Conical hopper design on the bottom section,to make sure dump out easily; 9)All sections can be disassembled and can be cleaned easily,100% Sanitary grade; 10)Multi-inlets to make sure that the pellets or hops can be soaked 100%; 11)The bottom ball valve is 3 ways,the middle port will be an inlet when you do recirculation,to make sure no blocking at the bottom of hop gun and to make sure 100% extracted at the bottom,no dead corners. | from 20liter 30liter 50liter to 1000liter is availble | |
| Hop Infuser/back tilting device | Pressurized design,quick-open Materials:SS304,Sanitary built 1XSemi-Automatic Gearbox,tilting device 1XAdjustable PVRV 1XHigh Quality oil filled pressure gauge 1XUpper inlet valve 1XLower outlet valve 1XPessure release ball valve 1XBasket Options: 1)Heavy duty Casters with legs 2)Motor for automatic tilting | 30/40/60/75/100gallon | |
