Product Description
Product Description
Product DescriptionFactory direct sell vertical metal slotting machine BK5032 with CE standardMachine features of slotting machine:1. Full protection.2. Equipped with external hand wheel.3. The main motor is the servo motor. 4. Optional TK13250 CNC rotary table is available. 5. The Y-axis screw nut type is preloaded with double nuts. 6. The vertical degree of Z direction and Y axis is no more than 0.02mm. 7. The rotary table is controlled by knd1000m-c numerical control system.8. The transmission mode is synchronous belt transmission with low noise and high transmission power.SpecificationunitBK5032BK5040The maximum length of rammm320400Ram adjustment strokemm315315Number of ram movementsn/min20-8020-80working desk sizemm800x610800x610Table travel (X, Y)mm350x400350x400The distance between the axis of the tool bearing hole and the forearm of the columnmm600600The distance between the end face of the cutter head support hole and the tablemm540620X direction motor torque(N.M)7.77.7Y direction motor torque(N.M)7.77.7Fast-movingX(m/min)55Y (m/min)55Ball screw (X)FFZD3205-3/P4FFZD3205-3/P4Ball screw (Y)FFZD3205-3/P4FFZD3205-3/P4Main motor powerKW44Machine tool weight (about)KG37003700Package dimensionsmm2800/2400/25002800/2400/2500Details ImagesApplicationCompany ProfileProfessional ServiceCustomers' FeedbackFAQQ1: Howis the warranty?A1: Warranty time is 13 months after BL date.Q2:Can we visit your factory before order?A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking. Q3:Do you have a stock?A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.Q4:What’s the MOQ?A4:One set only.Q5:How about your quality?A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.Q6:Do you have professional engineers?A6:Yes.we have professional engineers and designers. We can provide OEM services.Q7:Can you provide customized machines?A7:Yes, we can design and manufacture according to your specific requirements.
Company Profile
Jingjiang Fuji Technology Co., Ltd.
Our company offers variety of products which can meet your multifarious demands. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.
