Lk Potenza-III 750 Ton High Precision Servo Injection Molding Machine

Product Description

Brief Introduction
LK group specializes in the design manufacture and sales of die casting machines, high precision injection molding machines, CNC machine centers, and industrial integrated control systems. Our market share of die casting machines is over 60%, the injection molding machine ranks among the top 3 in China.
We have more than 10 production bases worldwide, most in domestic China, 1 in Taiwan and 1 acquired company IDRA in Italy, it is one of the world's leading die casting machine manufacturers. Our injection molding machine centers are Zhongshan in Guangdong and Ningbo in Zhejiang.
There are over 60 sales and service centers in the world with high-quality after-sales service. Our 24-hour prompt response system provide all-around fully coverage customer service.
Advantages
1. Enlarged design of the mode-locking structure
2. The whole machine layout is reasonable, the shape line is firm
3. The momentum is strong and the cycle is shorter
4. High response, low noise hydraulic system
5. High precision linear guide injection unit
6. Add cloud injection molding network interface
Use of application
Power Tool, Personal Care, Toys, Electrical Appliances, Body Parts, Steering Wheels, Small Packaging, Daily product
Technical Parameter List

	ITEM	UNIT	PT 750
Injection Unit	Shot Weight	g	2374	2965	3976	4346
	Screw Diameter	mm	85	95	110	115
	Injection Volume	cm3	2608	3259	4369	4776
	Injection Pressure	MPa	230	176	131	120
	Screw L/D Ratio	L/D	24.7	22	18.9	18.2
	Injection Rate	cm3/s	625	782	1049	1146
	Plasticizing Capacity	Kg/hr	262	324	410	432
	Screw Speed	r/min	140
	Hopper Capacity	L	125
Clamping Part	Locking Force	kN	7500
	Die Height (Min.-Max.)	mm	400-1000
	Opening Stroke	mm	980
	Space Between Tie Bars	mm	1000×960
	Ejector Stroke	mm	280
	Ejector Force	kN	270
Other	Pump Motor Power	kW	48.2*2
	Max Working Pressure	MPa	17.5
	Oil Tank Capacity	L	1080
	Heating Capacity	kW	51.8
	Machine Dimensions (L×W×H)	mm	11000x2400x2500

Products Display
Showroom Review
Factory Review

---
