1 Ton China Mini Wheel Loader for Sale (WSL100)

Product Description

1 Ton China Mini Wheel Loader for Sale(WSL100)
Specifications:
Powerful engine;
Modern apprearence and streamline outline with wider visibility;
Load-sensing hydraulic system;
And so on.
Features:
1. Compact structure, maneuverable movement suitable for narrow space operation
2. Close cabin with joystick control system
3. Extended wheelbase
4. High flow double output
5. Double accelerograph control
6. Auto-leveling system
7. Multi-function with a wide range of attachments
8. Hydraulic brake

Performance	1	Model		WSL50	WSL65	WSL70	WSL75	WSL75D
	2	Operating Load Capacity	Kg	500	650	700	750	750
	3	Bucket Capacity	m 3	0.25	0.47	0.45	0.55	0.44
	4	Max. Loading Capacity	Kg	1000	1300	1496	1720	1500
	6	Bucket Lifting Force	Kg	1200	1500	1800	1885	1800
	7	Arm Lifting Force	Kg	1000	1300	1340	1660	1500
	9	Max. Travelling Speed	Km/h	12	11.2	11.2	12.2	11.2
	11	Rated Flux	L/min	50	60	62.5	75	75
	13	Fuel Tank Capacity	L	50	60	57	83	75
	14	()Deadweight with Bucket	Kg	2200	2900	2800	3500	2900
Dimensions	15	Tyre		10.0/75-15.3	10-16.5	10-16.5	12-16.5	10-16.5
	16	Overall Operating Height	mm	3300	3535	3830	3900	3601
	17	Height to the Top of Cabin	mm	2000	2090	2150	2300	1575
	18	()Overall Length without Bucket	mm	2300	2650	2630	2800	2610
	19	()Overall Length with Bucket	mm	2900	3525	3360	3500	3390
	20	Dumping Angle at Max. Height	deg	40	55	36.5	37	40
	21	Dumping Height	mm	2050	2100	2290	2200	2068
	22	Dumping Reach	mm	790	750	419	640	405
	23	Rollback of Bucket on Ground	deg	31	31	29.5	31	38
	24	Rollback of Bucket at Full Height	deg	97	97	98	98	98
	25	Wheelbase	mm	891	991	992	1050	1195
	26	Ground Clearance	mm	150	210	204	190	188
	28	Front Turning Radius without Bucket	mm	1170	1260	1272	1360	1262
	29	Front Turning Radius	mm	2005	2090	2033	2200	2058
	30	Rear Turning Radius	mm	1430	1770	1590	1870	1588
	31	Rear Axle to Bumper	mm	980	1050	1020	1050	919
	32	Tread Width	mm	1080	1460	1393	1660	1641
	33	Width	mm	1300	1680	1678	1980	1926
	34	Bucket Width	mm	1300	1720	1710	2020	1966
Engine	35	Engine Model		Changchai 385	XC C490BPG	XC A498BPG	XC A498BPG	XC A498BPG
	36	Max. Torque	Nm	86.4	156	193	193	193
	37	Rated Power	Kw	25.7	36.8	45	45	45
	38	Rotating Speed	rpm	2500	2650	2500	2500	2500
	39	Number of Cylinders	pcs	4	4	4	4	4
	40	Displacement	L	2.54	2.54	3.168	3.168	3.168
Performance	1	Model		WSL85	WSL95	WSL100	WSL160
	2	Operating Load Capacity	Kg	850	950	1000	1600
	3	Bucket Capacity	m 3	0.5	0.55	0.5	0.7
	4	Max. Loading Capacity	Kg	1700	1900	2000	3200
	6	Bucket Lifting Force	Kg	2000	1885	2100	3500
	7	Arm Lifting Force	Kg	1700	1660	1800	2900
	9	Max. Travelling Speed	Km/h	12	11.5/23	12	11.5/23
	11	Rated Flux	L/min	75	62.5	75	79
	13	Fuel Tank Capacity	L	80	76.4	80	98
	14	()Deadweight with Bucket	Kg	3200	3500	3400	4120
Dimensions	15	Tyre		12-16-15	12-16.5	12-16.5	12-16.5
	16	Overall Operating Height	mm	3690	3900	3780	4170
	17	Height to the Top of Cabin	mm	1820	2300	2040	2170
	18	()Overall Length without Bucket	mm	3140	2800	2645	3164
	19	()Overall Length with Bucket	mm	3840	3500	3345	4000
	20	Dumping Angle at Max. Height	deg	40	39	45	36
	21	Dumping Height	mm	2330	2200	2900	2570
	22	Dumping Reach	mm	710	640	750	790
	23	Rollback of Bucket on Ground	deg	31	31	31	32
	24	Rollback of Bucket at Full Height	deg	98	98	98	97
	25	Wheelbase	mm	991	1117	1020	1310
	26	Ground Clearance	mm	205	190	260	205
	28	Front Turning Radius without Bucket	mm	1450	1360	1270	1558
	29	Front Turning Radius	mm	2280	2200	2100	2380
	30	Rear Turning Radius	mm	1970	1870	1745	2100
	31	Rear Axle to Bumper	mm	1180	1050	1010	1187
	32	Tread Width	mm	1500	1660	1500	1660
	33	Width	mm	1820	1980	1850	1980
	34	Bucket Width	mm	1820	2020	1900	2140
Engine	35	Engine Model		XC A498BPG	804D-33	Deutz D226B-4	1104D-44T
	36	Max. Torque	Nm	193	200	246	392
	37	Rated Power	Kw	45	47	53.84	74.5
	38	Rotating Speed	rpm	2500	2500	2500	2200
	39	Number of Cylinders	pcs	4	4	4	4
	40	Displacement	L	3.168	3.3	4.2	4.4

---
