| No. | Item | Parameter | Remark | |
| 1 | Suitable material | Type | Color steel, galvanized steel | |
| Thickness(mm) | 0.35-0.7mm | Test material standard 0.45mm | ||
| Yield strength (Mpa) | ≤300mm | |||
| Width (mm) | About 1220mm | |||
| 2 | Forming speed | About 10-15 m/m | Not include cutting time | |
| 3 | The motor of forming system (kw) | 5.5kw | Depends on the final design | |
| 4 | Hydraulic station power(kw) | 4kw | Depends on the final design | |
| 5 | Voltage requirements | AC380V, 50Hz, 3phase | According to the customer's request | |
| 6 | Roller material | #45 steel with heat treatment 58-62 degrees | ||
| 7 | Shaft diameter | 70mm solid | ||
| 8 | Control system | PLC with touchscreen | Delta brand | |
