Factory Price 2000kw Natural Gas Biogas Engine Power Generator

Product Description

20kw - 1000kw Landfill Gas motor Biogas Generator
Product Description:
We are professional manufacturer of gas and diesel generator set for alomost 20 years, our products mainly include natural gas generator, biogas generator, biomass generator, coal gas generator, syngas generator, coal-bed gas generator, coke oven gas generator, diesel generator etc.
Core features of biogas generator:
Manufacturer supply since 2008
Power supply range:20kw - 1000kw
Parallel system available for over 1 set generator
Standard component and assembly
Multi-option of control panel
With CE and ISO certificate
Biogas generator specification:
Fuel: methane,biogas natural gas, CNG,LNG.

Product Parameters

Model Number	LHBG10-1000
Brand Name	Lvhuan
Rated Power	10-1000 kw
Rated Speed	1000/1500rpm
Rated Frequency	50/60 Hz
Rated Voltage	400/230V
Phase	AC 3 phase 4 wire
Starting system	24V DC electric motor
Cooling method	water cooler
Lubricant method	pressure and splash
Isolation class	H
Protection	IP23
Power Factor	0.8 lagging
Exciting method	Brush less
Voltage Stability	≤±2%
Voltage Transient	≤±10%
Voltage Stable time	≤1 s

Engine Capacity	1.81-95L
Cylinder Number	2-16
Cylinder Diameter	100-190mm
Range	115-210mm
Heat consumption	≤9.8mj/kw.h
Oil consumption	≤1.63g/kw.

Main spare parts:
1. Control system: America Woodward control system
2. Controller: ComAp, Deepsea, Woodward
3. Ignition system: American ALTRONIC, including:magneto, high-tension coil
4. Starting system: DC 24V electric motor.
5. Mixer: IMPCO
6. Spark plug: STITT
Worksite requirements for generator:
The worksite needs to meet following basic requirements:
a) Ambient temperature between -40ºC~40ºC;
b) Relative humidity less than 95%(35ºC);
c) Site elevation not higher than 2500m;
d) For outdoor installation, simple rain shelter is required.
Gas requirements for generator:
1m from genset's pressure regulating valve of inlet
1. Temperature of biogas≤40ºC
3. CH4 content of biogas≥40%, variation rate≤2%/min.
4. H2S≤200mg/Nm3
5. NH3≤20mg/Nm3
6. Impurities particle size≤5μm, impurity content≤30mg/Nm3
7. Moisture Content of biogas ≤40g/Nm3
Purification of biogas has a significant impact on machine life and continuous running time!
Biogas generator features:
1.Pure copper water tank for best cooling effect
2.Famous component brand to ensure overall quality
3.Expansion fitting combined with shrinking fitting give high tightness to the system
4.Safety guarantee form electromagnetic valve as well as back-fire relief valve
5.Residual heat CHP recycle system available for choice.
Biogas generator Supply details:
Ignition system:We adopt ignition system of magneto which produced by American ALTRONIC company,including:magneto,high-tension coil,sparking plug.
Starting system: DC24V electric motor,12v190 adopt ST710 of direct-current.
Pressure charging system:Pulse Mixed-flow supercharger, compression ration is 1:8,meet engine's requirement for gas-flow rate.
Speed regulating system: EGS gas controller of American WOODWARD Company.
Service
1. Pre-sale service:
1) We will send our engineer to prospect the site of power station free of charge.
2) According to the situation of site, we will provide design drawings, such as power plant floor drawing, cooling system drawing, genset foundation, control room design, etc.

2. Sale service:
1) Operator training would be conducted by Lvhuan technicians during the process of commissioning or Factory training course in China,
2) Installation and commission of the genset would be instructed assisted by Lvhuan technicians at site.

3. After-sale service:
1) We have strong after-sale team, we will response within 24 hours and provide technical supports by phone or site guiding, help our clients to gain the biggeset profit.
2) For the quality problem, we will service for you free of charge during the guarantee period.
3) We provide one year guarantee period and lifetime service.
Plentiful spare part supply:
1. We have spart parts department, plentiful spare part supply for all genset model will guarantee genset lifetime running.
2.All parts were from original factories or professional factories,complete in specification, keep good quality.
FAQ:
1. How to choose the right model?
To choose a right model, we need to know required continuous output power, local voltage and frequency and fuel (such as diesel, natural gas, biogas, biomass gas, coal gas, syngas, etc.). For biomass power plant and coal gas power plant, some clients may doesn't have gasification system, then we need information about raw material.

2. What's the warranty?
The warranty is one year. We will offer free service and spare parts during warranty period. Lifetime service will be provided by our trustworthy after-sale team.

3. How to do the maintenance?
Operator training will be provided by our technician. After training, local operator can do the basic maintenance by themselves according to our maintenance manual.

4. Will be operation training offered?
Yes, operator training would be conducted by our technicians during the process of commissioning or factory training course in China.

5. What's about the installation and commissioning?
Installation and commissioning of the genset would be instructed assisted by our technicians on site.
Product picture

---
