| SPECIFICATION | |
| Item | GBC5201 |
| Engine model | 1E44F-5 |
| Displacement | 52cc |
| Rated pow | 2.1kw/7500 rpm |
| Carburetor | Pump film |
| Gas/oil mix ratio | 40:1 |
| Pipe diameter | 26mm |
| Ignition | CDI |
| Fuel tank capacity | 1200 ml |
| Idel Speed | 3000+200rpm/min |
| Max. Speed | 9000+200rpm/min |
| Harness | single shoulder |
| Color | orange & black or clitens-demanded |
| N.W. /G.W. | 7.8kg/8.8kg |
| Packing | 1 carton/pcs |
| Carton | 5 Layer brown paper |
| Handel | "P" type(accorfding to CE ) |
| Working shaft length | 88cm(with engine) |
| Meas | 1070mmx315/125mmx290 mm |
| 40'HQ | 990pcs |
| Certification | CE/EUV/EMC/MD/GS |
