Ce Certificated Limestone Crusher for Consuction Aggregates

Product Description

Ce Certificated Limestone Crusher for Consuction Aggregates
40% moisture approval.
Adjustable 0-25mm discharge.
The final product in excellent cubic shape is improved, needle-like and flake-like shape products can be reduced, and energy consumption can be reduced 40%.
The application of the CE Certificated Limestone Crusher For Consuction Aggregates:
Impact Crusher is optimized after adopting advanced techniques,and the capability of impact crusher got advanced very much!Impact Crusher is mainly used to crush many kinds of large, medium, small materials .the side length of impact crusher is less than 500mm, and compression resistance of impact crusher should not be more than 350Mpa. The impact crusher is widely used in building material, hydroelectricity,artificial stone and sand, highway, etc.
Working principle of the CE Certificated Limestone Crusher For Consuction Aggregates:
impact crusher is a kind of broken by impact energy to the material of crushing machinery.When the impact crusher works, the motor drives the rotor rotate of the impact crusher with high speed, on the rotor where installed the hammers. When the materials get into the area which the hammers effect, under the impact function of the hammer at a high speed, the materials are thrown to the impact device above the rotor continuously. And then the materials are rebounded from the impact liner to the area where the hammers effects for being recrushed. The materials from large to small all to be crushed at the impact chamber repeatedly. The process won't stop till the material are crushed to the required size and then discharged from outlet of the impact crusher.
Characteristics of the CE Certificated Limestone Crusher For Consuction Aggregates:
Impact plate with a special shape,wear- resistant liner plate,specially in hard mining crush,high efficicency and reduction ratio.the final production is cubic shape,required adjustment the output feed fineness,simplifying the process of the crushing.
CE Certificated Limestone Crusher For Consuction Aggregates technical parameters:

Model	Specification (mm)	Feeding size(mm)	Max feed size(mm)	Capacity (t/h)	Motor power(kw)	Weight(kg)
PF-0607	644*740	320*770	100	10-20	30	10216
PF-0807	850*700	400*730	300	15-30	30-45	11138
PF-1008	1000*800	400*830	300	30-50	37-55	12206
PF-1010	1010*1050	400*1080	350	50-80	55-75	13138
PF-1210	1250*1050	400*1080	350	70-120	110-132	15200
PF-1212	1250*1250	400*1300	350	100-150	132-160	17025
PF-1214	1250*1400	400*1430	400	130-180	160-200	19015
PF-1315	1320*1500	860*1520	500	160-250	180-260	24600
PF-1320	1320*2000	860*2030	500	300-350	300-375	29800
PF-1520	1520*2000	980*2980	700	400-500	400-480	38600

Zhengzhou Hengxing Factory Limestone crusher package and shipping :
Limestone crusher successfully case :
For more limestone crusher price and technical specifications ,please contact :
Contact:
Sara Pang
Mobile phone : 0086137 8347 1727

---
