US$10,000.00-20,000.00
|
1 Set
(MOQ)
|
Basic Info.
Computerized
Computerized
Certification
CE, ISO9001:2008
Product Name
PVC Plast- Steel Profile Extrusion Line
Processing Type
Profile Extrusion
Usage
Window/Door/Door Frame
Contactor
France Schneider Contactors
Temperature Control
Japan Omron
Transport Package
PE Film Winding Wrapping
Specification
110mm-400mm
Production Capacity
500 Sets/Year
Product Description
PVC Windows Profile Extrusion Machine
GPM series PVC profile Production Line is mainly used for many profile product. The unit consists of conical double double extruder, mold, vacuum forming tank, haul-off machine, cutting machine, stacker and so on. And the line can be equipped with Comptroller thickening instrument or computer .
YF Series PVC profiles extrusion line is mainly used in PVC plastic steel doors and windows profile,window panels, perforated pipe threading and foam profile extrusion products. The production line according to the different requirements of customers and cross-sectional shape of the mold, you can choose the most suitable twin-screw extruder , and equipped with the appropriate vacuum form-ing . Cuttting and other auxiliary traction.
| Conical twin-crew extruder technical specification for PVC Windows Profile Extrusion Machine |
| Model | Screw Diameter(mm) | Main Moter(kw) | Output Capacity(kg/h) |
| GSZ-45 | 45/100 | 15/18.5 | 60/80 |
| GSZ-51 | 51/105 | 18.5/22 | 80/110 |
| GSZ-55 | 55/110 | 22/30 | 120/150 |
| GSZ-65 | 65/132 | 37/45 | 280/350 |
| GSZ-80 | 80/156 | 55/77 | 380/450 |
| GSZ-80A | 80/173 | 75 | 500/650 |
| GSZ-92 | 92/188 | 110/132 | 700/850 |
| GSZ-95 | 95/196 | 132/160 | 1000 |
| Downstream line technical specification |
| Model Max.product width(mm) Total power(kw) Water Cooling(m³/h) |
| GYF110 110 16 4 |
| GYF240 240 21-32 7 |
| GYF300 300 21-32 7 |
| GYF400 400 21-32 7 |
Product Display of PVC Windows Profile Extrusion Machine
Special configuration:
1. GearBox
High efficiency single screw extruder , high output.
2.Feeding mechanism
Parallel twin-screw feeder, suitable for the feeding of powder and mixture .
3.Haul-off
New-designed haul-off structure , strengthen the design of torque .
4.No-dust Cutter
High precision cutting, no dust and low noise.
>>
