Ds-618b Automatic Toe Lasting Machine for Shoe

Product Description

DS-618B Automatic Toe Lasting Machine for shoe
This machine is applicable for lasting the toe of all kinds of man and lady shoes and sports shoes.
The crosshead projection light will ensure accurate last positioning.
The pressure head mechanism adopts adjustable two-segment pressure to ensure steady pressure and achieve the best pressing result.
The all-round band and wiper with special tracking system make sure that each part of the upper is tightly against the shoe last after lasting without any point angle but with smooth appearance.
The 9 independent pincers can be adjusted independently.
The pincer plate can be also adjusted according to the shoe size with independent moving function, and it is also suitable for different types of shoe last.
The machine is of easy, rapid and accurate adjustment.
The pressure, position, and speed of each device may be adjusted from outside directly and conveniently.
1,Characteristics
DS-618B Automatic Toe Lasting Machine is a clamping shoe vamp with nice claws molding machine, designed for shoe sole molding . Make use of this machine to manufacture your products, which can meet the demand of attaching shoe vamp with the shoe last smoothly. The machine is featured with convenient operation , high efficiency, steady quality, easy maintenance ,and suit for manufacturing the children shoes , sports shoes, lady shoes , men shoes , riding boot , gentlemen shoes and other special work shoes , mountaineering shoes and so on.
(1) Main features:
A. Universal tightening band and specially-designed wiper ensure shoe vamp attaching shoe last equably without any shagginess after lasting.
B. Pressure head device adopts adjustable two-sections pressure, which make the working piece during wiper tightening and final pressing reach the best impression.
C. Independence nice claws is adjustable, which can be suit for any shape shoes toe part tightening .
D. Each claw has function of automatic cogging-down. Operator can select some claws to be cogged down according with shoe vamp tightness degree.
E. Wiper with function of adjustable speed and inching motion is convenient for adjustment that controlled vamp tightening.
F. Auxiliary wiper structure cooperating with nice claws of toe part make the vamp attaching shoes last tightly.
G. Cross projection lamp can help laying toe part of shoe last in the right position .
H. Opening or closing of turn-plate of right and left claws is adjustable and independence, which can manufacture the right and left shoe separately.
I.Rotating of second claw is independence and adjustable, which is more quick and convenient for replacing shoe last.
J. Adjustable inner and outer brace table can move upward or downward, which is convenient for manufacturing shoes with any size.
2,Main parameters:

Motor power	2.2 kw	Working voltage	440V/50HZ	Heating power	1.0 kw
Working pressure	5 Mpa	Efficiency	1600pair/8h	Net weight	1135 kg
External dimensions(L*W*H) :1710mm×950mm×1950mm
Package dimensions (L*W*H):1760mm×1000mm×2230mm

---
