20 Ton Per Day Automatic Agro High Quality Combined Rice Mill Machine Complete Rice Milling Machine

Product Description

CTNM20 COMPLETE SET COMBINED RICE MILLING EQUIPMENT
Strong Pre-cleaning Type
Double-layer Drum Cleaning, Destoning, Husking, Separating, Whitening, Grading
by ONE-TIME operation
1. Product Introduction
CTNM20 Complete Set Combined Rice Mill combined with TZQY54 drum paddy cleaner and QSX45 de-stoner, 8'' rubber roller husker, gravity paddy separator, large volume inhale-air emery roller rice mill, rice grader, conveyors. Revolutionally equipped with drum type cleaning machine which engifted very strong cleaning efficiency, great brown rice separating and rice whitening performance, easy operation, convenient maintenance and high productivity, reducing the leftovers at the maximum level; with direct optional brown rice outlet, provides users with a flexible multifunctional rice milling solution. At the meantime, we reserved the possibility to match the follow up equipment such as multi-layer rice grader, rice polisher, color sorter etc, to improve the milling performance or extend its functions.

1	Feeding Hopper	2	Single Elevator
3	TZQY54 Drum Type Paddy Cleaner	4	QSX45 Destoner
5	Double Elevator	6	MLGT20 8" Rubber Roller Husker
7	MGCZ70×6 Gravity Paddy Separator	8	15 Large Volume Inhale-air Emery Roller Rice Mill
9	Rice Grader	10	Electric Control Box

2. Product Features Unibody base designed for convenient transportation and installation, stable operation, low space occupation. High-efficiency double-layer drum-type cleaning sieve, strong precleaning performance. It improves production efficiency by the unique rehulling leftover paddy design. Innovative emery roller whitening technology, low rice temperature, less bran remains, improves the rice quality. Smooth processing flow, easy operation for just one person. Independent safe electric control system for more convenient operation. Improved transmission system extends the duration of consumption parts Modula design, reserves connectivity with follow-up equipment to double mill, grade and sort for better rice quality. Low investment and high yield




3. Main configuration and technical parameters:

Model&Spec.	CTNM20A Basic configuration	CTNM20B A+ Rice grader	CTNM20C A+Rice grader+Polisher
Cleaner and de-stoner	TZQY54/QSX45	TZQY54/QSX45	TZQY54/QSX45
Husker	MLGT20	MLGT20	MLGT20
Paddy separator	MGCZ70×6	MGCZ70×6	MGCZ70×6
Rice mill	NF15A(1pc)	NF15A(1pc)	NF15A(1pc)
Rice grader	Basic rice grader	MJP50×2	MJP50×2
Rice polisher	/	/	MPGT12.5
Single elevator	DTG19/8-1pc	DTG19/8-2pcs	DTG19/8-3pcs
Double elevator	DTG19/8-8	DTG19/8-8	DTG19/8-8
Technical Parameters:
Output(kg/h)	800-1000	800-1000	800-1000
Rice milling rate (%)	68-72%	68-72%	68-72%
Power(kw)	25.32	26.62	49.87
Overall dimension(mm)	3300×1200×3400	3800×1200×3400	5000×1200×3400

4.Packing: Wood Case

5. Full Set Rice Mill Process Lines:
6. Contact us
Diana Su
Overseas Dept.
Hunan Sunfield Machinery Co.Ltd
Address:Hexiang Science and Technology Park, No.98, Lixiang Road, Changsha Economic & Technical Development Zone, Changsha, Hunan, China

---
