| US$1,000.00-20,000.00 | 1 Piece (MOQ) |
| Saw diameter | 140~400mm |
| Bore diameter | 15.88~80mm |
| Body thickness | <8mm |
| Side relief | 0°~4° |
| Side angle | -5°~+5° |
| Hook angle | -5°~+30° |
| Pitch | <80mm |
| Tip length | <20mm |
| Wheel power | 0.75KW |
| Wheel diameter | 80~120mm |
| Wheel speed | 4800RPM |
| Wheel linear velocity | 30m/s |
| Grinding speed | 2mm~10mm/s |
| Processing efficiency | 4~15tip/min |
| Grinding accuracy | <0.02mm |
| Coolant tank | 70L |
| Input voltage | 380V 50Hz(OR 220V 60Hz) |
| Power | Approx 3.7KW |
| Dimension | 2800mm*1400mm*1900mm |
| Weight | 2200kg |
