Hikvision Dahua CCTV Turbo HD Security Camera Network Video Recorder DVR NVR

Product Description

Product Description
Hikvision, dahua, imou
Hikvision NVR Turbo HD 4-ch 5 MP 1U H.265 Network Security Vedio DVR (DS-7204HUHI-K1/E)
4 channels and 1 HDD 260 case DVR Efficient H.265 pro+ compression technology Encoding ability up to 8 MP lite @ 15 fps, 5 MP @ 12 fps 5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP) Up to 8 network cameras can be connected. Recording Encoding Resolution When 8 MP Lite mode is not enabled:
8 MP/5 MP/3K/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
When 8 MP Lite mode is enabled:
8 MP Lite/5 MP/4 MP/3MP/1080P/720P/WD1/4CIF/VGA/CIF

Video Bit Rate32 Kbps to 10 Mbps Frame Rate Main stream:
When 8 MP Lite mode is not enabled:
8 MP@8 fps/5 MP@12 fps/3K@12 fps/4 MP@15 fps/3 MP@18 fps
1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)
*: 8 MP@8 fps is only available for channel 1 of DS-7204HUHI-K1/E.
When 8 MP Lite mode is enabled:
8 MP Lite/5 MP@12 fps/4 MP/3MP/1080P/720P/WD1/4CIF/VGA/CIF@15 fps
*: 8 MP Lite is only available for DS-7204HUHI-K1/E.
Sub-stream:
WD1/4CIF/CIF@25fps (P)/30fps (N)

Video CompressionH.265 Pro+/H.265 Pro/H.265/H.264+/H.264 Dual StreamSupport Stream TypeVideo, Video & Audio Audio CompressionG.711u Audio Bit Rate64 Kbps Video And Audio Audio Input1-ch, RCA (2.0 Vp-p, 1 KΩ),4-ch via coaxial cable Audio Output1-ch, RCA (Linear, 1 KΩ) Synchronous Playback4-ch IP Video Input 2-ch (up to 6-ch)

Enhanced IP mode on:
4-ch (up to 8-ch), each up to 4 Mbps, Up to 8 MP resolution, Support H.265+/H.265/H.264+/H.264 IP cameras


Enhanced IP mode on:
4-ch (up to 8-ch), each up to 4 Mbps
Up to 8 MP resolution;Support H.265+/H.265/H.264+/H.264 IP cameras
HDTVI Input8 MP, 5 MP, 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25 HDCVI Input5 MP, 4 MP, 1080p25, 1080p30, 720p25, 720p30 CVBS InputPAL/NTSC Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input) Analog Video Input4-ch;BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection AHD Input5 MP, 4 MP, 1080p25, 1080p30, 720p25, 720p30 CVBS OutputN/A HDMI/VGA Output HDMI:1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz HDMI and VGA simultaneous output
VGA:1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Network Network ProtocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF Remote Connections32 Network Interface1, RJ45 10M/100M self-adaptive Ethernet interface Auxiliary Interface CapacityUp to 10 TB capacity for each disk Serial InterfaceN/A USB Interface2 × USB 2.0 Alarm In/OutN/A SATA1 SATA interface General Consumption(Without HDD)≤ 6 W Working Humidity10% to 90% Power Supply12 VDC Working Temperature-10 °C to +55 °C (+14 °F to +131 °F) Dimensions(W × D × H)265 × 225 × 48 mm (10.4 × 8.9 × 1.9 inch) Weights (Without HDD)≤ 1.6 kg (3.5 lb) Company Profile
PAIZE TECHNOLOGY LIMITED was founded in 2015, we have the professional sales and technical support team in Hangzhou. Since established, we are always focusing on the distribution of security products, and cooperate with the top3 manufacturer in security field. Our business covers many countries including Europe,
Africa,America, Asia, Australia, and so on.
The products we sell include DVRs, NVRs, IP cameras, HDCVI cameras, and so on. All the products we providing are original international versions and OEM orders are also welcome.
We will make great efforts to offer excellent pre-sales, sales, and after-sales service.
We adhere to the principle of "Customer Upmost, Service First" We are sincerely looking forward to your cooperation!


FAQ 1)Why choose us?
Comptetive Price:Our company has built up friendly relations with Dahua,Hikvision, IMOU since 2015.and we work with factory directly.
Friendly and fast service:We have professional tech-support team to deal with problems before and after sales. Don't be afraid if you meet probelms.We are here!

2)When will you ship my order?
Products are popular,so inventory is always changing. Please contact us before you pay and we will confirm the date with you.

3)Can I installate the security cameras by myself?
Of course!There is always a user manual in the packaging box.You can contact us directly if you meet any problems.We are here!
4)How about warranty?
2-year warranty period(since the date you receive the order). some products are 3 years and some are 5 years, welcome to confirm with us.
5)How about the shipping cost?
Shipping cost is depend on weight, we have very cost-effective agent for you.
6)Your products sell to whom?
Retail and wholesale customers are both welcomed.

If interested in this camera,pls contact us today and know the most latest information!

---
