Product Details
Product Description
Product Description
Axle: 3 Axle FUWA
Load Weight: 20-60 tons
Dimension: 13300x2500x1550mm
Application: transport bulk cargo, livestock
Delivery: 7-20 Days
The Fence Cargo Trailer with Hydraulic Lift Gate features a lift gate design at the rear for easier loading and unloading of cargo. This fenced cargo trailer can be used to transport not only bulk cargo but also livestock such as pigs, cows and sheep. The surface of the trailer is painted with a two-component paint that lasts longer and doesn’t chip off easily.
PRODUCT ADVANTAGES
Our lifted cargo trailer frame adopts a space frame structure with longitudinal beams welded and transverse beams running through as a whole. It can take into account the strength, rigidity and toughness of the frame, with strong carrying capacity and no deformation.
The lightweight design not only reduces tire wear, but also reduces truck fuel consumption. Under the same road conditions and carrying capacity, the fuel consumption of 100 kilometers can be reduced by more than 1.3 liters.
We use imported famous brand brake pads and implant wear alarm device. Effectively guarantee the braking performance of the fence cargo trailer in the running process.
Fence Cargo Trailer with Hydraulic Lift Gate uses air suspension. It is able to drive smoothly even under poor road conditions, which is more suitable for transporting livestock.
Dimension: 13300x2500x1550mm
Loading capacity(ton): ≤60T
Axles: 3 axles, 13T/16T ,FUWA/ BPW/ Huajing Brand
Tire: 6 units, 12.00R22.5 or 315/80R22.5
Rim: 9.00-22.5 or 9.75-22.5
Suspension: Airbag suspension
King Pin: JOST brand 2.0 inch
Landing Gear: JOST brand 28tons
Platform: 3mm-thick checkered plate
>>
