| Specification | |||
| LCD Panel Parameter | Panel Size | 65 / 75/ 86/ 100 inch DLED | |
| Max. Brightness | 300-350cd/m² | ||
| Max. Resolution | 3840*2160 | ||
| Contrast Ratio | 5000:01:00 | ||
| Panel Life | 50000 hours | ||
| Viewing Angle | H178/V178 | ||
| Touch Panel Parameter(optional) | Touch Type | Fingers or any opaque objects | |
| Touch point | 20 touch points | ||
| Transparency | ≥80% | ||
| Integral Touch | infrared multipoint | ||
| OS | Win11 / Android 14.0 | ||
| Communication | USB | ||
| Touch Principle | infrared induction | ||
| Touch Accuracy | ±1 mm | ||
| linearity | ±3 mm | ||
| specification parameter | CPU | Quad-core ARM Cortex-A55 | |
| ROM | 4GB | ||
| SSD | 32/ 64GB | ||
| Wi-Fi | 2.4GHz/5GHz | ||
| PORT | USB 3.0×1,USB 2.0×2,HDMI×1, TOUCH USB×1, Type-C×1,RJ45:×1,RS232:×1,HDMI 1:×1,HDMI 2:×1,AV IN:×1,AV OUT:×1,Earphone:×1,SPDIF OUT:×1,Front HDMI:×1,OPS USB:×1 | ||
| The weight of the whole machine | Net weight | 35kg | |
| Gross weight | 42kg | ||
| Overall package size | 1600×200×1000mm(length*width*height) | ||
| Audio parameters | Sound power | (8Ω10W)*2 Stereo surround sound | |
| Power supply parameters | Rated power | ≤260W | |
| Standby power | ≤0.5W | ||
| Enter the power supply | 100~240V AC, 50/60Hz | ||
| Working environment | Operating temperature | 0~40ºC | |
| Operating humidity | 10%-90% | ||
| Storage temperature | -20~60ºC | ||
| Store humidity | 10%-90% | ||
