200X360mm Closed-Loop Control Sumore Slant Bed Specification CNC Turning Lathe

US$11,000.00-15,000.00 1 set (MOQ)

Basic Info.

Model NO.
stc2118s
Movement Method
Contour Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
Economical CNC Machine Tools
Certification
CE
Condition
New
Max Swing Over Bed mm
300mm
Max Work Piece Length mm
320mm
Spindle Taper
Mt3
Spindle Motor Power
1.5kw
Spindle Spindle Power
100-3000 Rpm
Spindle Spindle Bore
20mm
Overall Diamension(Lxwxh)
1,200 X 940 X 770 mm
CNC Control System
GSK/Siemens/Fanuc
Machine Type
Automatic CNC Lathe Machine
Key Word
CNC Lathe
Word2
CNC Lathe Machine
Key Word1
CNC Lathe Machine Price
Similar Model
Ikc4s Ikc6s Ikx1s Ikx3s Kc6
Similar Brand
Sumore Sieg Kaida Weida Timeway Luzhong Sjr Borui
Transport Package
Plywood Box
Specification
200X360mm
Trademark
SUMORE
Origin
China
HS Code
8458912090
Production Capacity
10

Product Description

Product Description
China NO. 1 quality !!! HOT!!! SUMORE brand 8PCS OR 4PCS ATC45 Degree Small Slant Bed Mini CNC Machine Lathe Sale STC2118S
Hoooooot !!!!! High Accuracy 1.5kw Servo Motor Hiwin Linear High Speed Slant Bed 3000rpm Siemens808da 8pcs Hongda Turret Small CNC Turning Center Lathe Machine
Shanghai SUMORE NEW design slanting bed 8 pcs ATC high speed mini to small cnc lathe machine for sale GSK SIEMENS FANUC different control system available High speed small turning center mini cnc lathe machine to metal aluminium copper2 Axis Metal Aluminium Processing Slant Bed Automatic CNC Lathe Machine Turning Center with CE Certification
Main specification of cnc lathe machine:
Processing material: aluminum, copper, metal etc.
Swing over bed: 300mm
Spindle taper: MT3
Spindle bore: 20mm
Control system: PC BASED MACH, OR SIEMENS

Model
STC2118S
Swing over Bed
300 mm
Maximum Travel on X Axis
120 mm
Maximum Travel on Z Axis
320 mm
Moving Speed on X Axis
3,000 mm/min
Moving Speed on Z Axis
3,000 mm/min
Spindle Bore
20 mm
Spindle Speed
100 - 3,000 rpm
Bed Style
45° Slanting

X Axis: Beeline Leading Orbit

Z Axis: Beeling Leading Orbit
Tool Post Size
12 x 12 mm
Tool Position
8
Spindle Taper
MT3
Tailstock Taper
MT2
Tailstock Sleeve Diameter
30 mm
Tailstock Travel
50 mm
Positioning Accuracy
0.010 mm
Repeatability Accuracy
0.0005 mm
Motor Power
1,500 W
Power of motor
400 W
Voltage and Frequency
220 / 110 v
Overall dimension (LxWxH)
1,400 x 770 x 1,600 mm
Packing Size
1650*1090*1600 mm
Net/Gross Weight
620/700 kgs


Company Profile
As the professional and experienced manufacturer of lathe, mill , drill , cnc and other tools ,Shanghai SUMORE Industrial Group has been in this filed for more than 20 years.
We have got the certificates of CE, GS ,Rohs , UL ,etc . Also we have been in business with GSK ,Siemens ,Faunc and other famous companies within 50 countries all over the world.
Whether you need the standard or the customerised products , please contact us directly . Our professional and experienced engineers and after sale service team will meet your needs.
Hope to cooperate with you!
