Electro Magnet Still Plate Lifting Magnet with Comprehensive After-Sales Service

Product Description

√ Elevate to the next level with our capability to lift single or multiple steel bars/rebars simultaneously. This feature ensures efficiency and productivity in your operations.
√ Our advanced lifting technology supports the elevation of steel materials, even when distortion or deformation is present, maintaining integrity and performance.
√ Experience unparalleled stability with our large magnetic permeability depth, delivering steadfast and reliable adsorption for all your lifting needs.
√ Enjoy versatility and precision with our motorized beam length adjustment, which seamlessly integrates into your workspace without interfering with non-steel objects.
√ Proudly presenting our patented innovation, protected under Patent Number: ZL201020522632.1, a testament to our commitment to pioneering technology.
Product Description
What is Electro Permanent Magnetic Technology?
Electro permanent magnet technology revolutionizes control over magnetic fields using electricity, transforming permanent magnet materials into a state of magnetic or non-magnetic force. This cutting-edge application technology empowers independent attraction or release of materials with remarkable precision.
Magnetized State: Harness the power of an electromagnetic coil's instantaneous excitation current, seamlessly switching the magnetic field state of reversible magnetic materials. This forms a closed-loop magnetic field that envelops the magnetic poles, delivering robust adsorption with zero magnetic loss, heat, noise, or energy consumption, as illustrated in Figure 1.1.
Demagnetized State: In the magnetized state, a secondary excitation current adjusts the built-in circuit, altering the reversible magnetic field. This convergence internalizes the magnetic field within the permanent magnet, ensuring the material's release as the surface magnetic field dissipates, as depicted in Figure 1.2.
About Electro Permanent Magnet
Our Electro Permanent Lifting Magnet System is the epitome of safety, unaffected by power outages or short circuits. With no need for UPS battery systems, it offers unwavering suction power from permanent magnetic materials. This guarantees the safety of materials, which can only be released post-demagnetization, providing the highest level of security for users.
Electro Permanent Magnet Advantages:
1. Economical, Energy-Saving, and Environmentally Friendly
Our system only consumes electricity during the brief moments of magnetic charging and demagnetization, requiring no power throughout operation. This results in a substantial reduction in electricity consumption—over 95% less than conventional electromagnets—drastically lowering operational costs.
The lightweight design of both the lifting magnet and control system reduces equipment load, enhancing lifting capacity and optimizing performance.
2. High Security
The Electro Permanent Lifting Magnet draws its magnetic prowess from two distinct types of permanent magnetic materials, achieving a formidable magnetic force of up to 16 kgf/cm². With zero reliance on electricity during operation, it mitigates risks associated with power failures or cable damage, ensuring enduring security without attenuation over time.
3. Ease of Use
Streamlined electronic control operations with simple charge and demagnetization buttons make usage effortless, completing magnetization and demagnetization in just 0.1-1 seconds. Benefit from enhanced efficiency, as the permanent magnet system requires no wear-prone parts or specific maintenance—just a clean surface for consistent, durable, and practical use.
After demagnetization, residual magnetic force is virtually nonexistent, ensuring that even the smallest magnetic particles don't adhere to the magnetic pole surface, preserving the integrity of your materials.
4. Unique, Flexible Product Design
Our lifting permanent magnet boasts a unique modular design, dual magnetic source technology, and a distinct manufacturing process, resulting in an innovative internal structure that sets it apart from the rest.
5. Exceptional Functionality
The Electro Permanent Lifting Magnet System stands as a paragon of safety and reliability, offering unparalleled security with its ingenious design. Immune to power failures, it forgoes the need for a UPS battery backup, ensuring continued operation. Utilizing the potent energy of permanent magnetic materials, this system delivers enduring suction power, guaranteeing material safety at all times. Only when touching down can materials be demagnetized, ensuring an unmatched level of security for end users.
Electro Permanent Lifting Magnet VS Electromagnet

SEQ	Compare Content	Electro Permanent Lifting Magnet	Electromagnet
1	Magnetic	Permanent magnet Material: Reversible magnet steel,	Electricity: Magneticfield generated by Currentthrough the coil
	source	fixed magnet
2	Principle	The magnetic field is turned on or off by an	Power on generated magnetic field, power off no magnetic field
	mechanism	instantaneous current
3	Security	All steel surface, oil&water-proof, no aging issue	Epoxy resin sealed, may occur aging and shedding issue in5
			years later, need repair.
4	Reliability	The suction is constant and does not attenuate over time	Suction is influenced by the heat caused by current, the coil is
			easy aging if use long time.
5	Durability	Permanent magnet no magnetic attenuation, magnetic
	and	module is maintenance-free.	Internal coil aging fast, the UPS battery need to be replaced
	maintenance		regularly, need to preparethe accessories.
6	Operating	Only in the moment of magnetization and	Need long-term electricity power during working, big power
	costs	demagnetization need electricity, no need power	consumption, commonly known

Packaging & Shipping
Electro Permanent Magnet System Composition (Standard)
1. Electro Permanent Magnet
The heart of magnetic force, creating direct contact and secure adsorption with the work piece.
2. Control System (including sound and light indicating system)
Manages magnetization/demagnetization processes and handles the collection and processing of all operational signals.
2.1. Long Distance Controller (optional)
A compact mini control cabinet ideal for Crane Cabs or other space-constrained locations.
2.2. Remote Controller (optional)
Compact mini control cabinet perfect for use in Crane Cabs or other compact locations.
3. Cable Retracting Device
Effortlessly manages the pulling in and out, release, and collection of cables.
4. Beam
Collects and transmits the tension from the permanent magnet.
Product Pictures:
Certificates:

---
