Max. lifting capacity: 40,000kg
Max. lifting height: 4.7M
| Max. lifting capacity | Ton | 40 |
| Max. lifting moment at min. range of the boom (392kN * 1.22M) | kN.m | 478 |
| Max. lifting moment at max. range of the boom (78.4kN * 4.5M) | kN.m | 353 |
| Boom length | m | 6.5 |
| Max. lifting height of the hook | m | 4.7 |
| Hoisting speed (6times) | m/min | 6 |
| Time of change range | s | 30 |
| Chassis model | | DGY-40S |
| Engine model | | CUMMINS NT855-C280 |
| Engine power | kW/rpm | 169/1800 |
| Track gauge | mm | 2250 |
| Track length on ground | mm | 4910 |
| Track shoe width | mm | 1050 |
| Hydraulic pump model | | CB-P63/63 |
| Hydraulic pump pressure | Mpa | 20 |
| Lifting winch | Hydraulic driven, planetary transmission, free-fall function |
| Rated pulling force of single rope (3rd layer) | N | 55000 |
| Wire rope diameter | mm | 18 |
| Ranging winch | Hydraulic driven, planetary transmission |
| Max. grade ability | o | 20 |
| Operation temperature (std.) | oC | -20 ~ +40 |
Overall dimension
(LxWxH) | with boom | mm | 5950x5100x7300 |
| without boom | mm | 5950x4100x3300 |
| Ground pressure | without load | Mpa | 0.034 |
| Operation weight | kg | 35000 |
