Heavy Duty- Disc Harrow

Product Description

BZ series heavy-duty off-set disc harrows are mainly used for cleaning away stubble of plants before tillage, or uncultivated land and in sticky heavy clay soil fields. They could also be used as a plow for primary tillage in dry cultivated fields. Their discs have been divided into front and rear two gangs notched discs, the dislocation of the design for front and rear disc gang, and disc gang on both sides of V to disc overall non-symmetrical, work Angle can be adjusted. The surface of the field after harrowing is level and the crushing and clearing ability of the harrow is satisfactory.
The series disc harrows are using rigid steel mail body, fitted with hydraulic rubber wheel for transportation and spring leveling equipment. They are strong and durable and easy to be hook up, simple to be adjusted, and easy to be transported and change direction on the edge of fields, especially suitable for large farm.

Model	1BZ-2.0	1BZ-2.2	1BZ-2.5	1BZ-3.0	1BZ-3.4	1BZ-4.0	1BZ-4.4
	5020x2250x1160	5120x2400x1180	5120x2920x1180	5120x3490x1180	5120x3960x1180	5680x4300x1180	5580x4680x1180
Overall Dimension (LxWxH) (mm)
Weight (kg)	1180	1260	1380	1500	1750	1950	2400
Working width (m)	2	2.2	2.5	3	3.4	4	4.4
Quantity of disc	18	20	24	28	32	36	40
Spacing of disc (mm)	230
Dia. of disc (mm)	660 (650)
Max. working depth (mm)	200
Ground clearance (mm)	>160
Linkage	Trailed
Productivity (ha/h)	1.1	1.3	1.4	1.7	1.9	2.4	2.8
Matched power (kw)	47.7~59	55~66.2	58.8~74	66.2~88	73.5~100	95~120	100~132

---
