Product Details
Product Description
Product Description
Specification :
item
| ball eye
|
Finish
| hot dip galvanizing
|
Material
| carbon Steel
|
Place of Origin
| China
|
Brand Name
| DS
|
Model Number
| QP-7
|
Standard
| GB
|
Size
| 10-100mm
|
Q, QP TYPES BALL-EYES
Dimensions of ball and socket for the special type are in accordance with "dimension of ball and socket coupling of sting insulator units " IEC-120 and "Dimension of hanging insulator units for high voltage transminssion line" GB4056-83
| Catalog NO. | Dimensions(mm) | Designated size of coupling | Rated Failing Load(kg) | Weight(kg) |
| d | Ø | b | d1 | h |
| Q-7 | 17 | 22 | 16 | 33.3 | 50 | 16 | 70 | 0.3 |
| QP-7 | 17 | 20 | 16 | 33.3 | 50 | 16 | 70 | 0.3 |
| QP-10 | 17 | 20 | 16 | 33.3 | 50 | 16 | 100 | 0.3 |
| QP-12 | 21 | 24 | 20 | 41.0 | 60 | 20 | 120 | 0.5 |
| QP-12G | 17 | 24 | 17 | 33.3 | 60 | 16 | 120 | 0.4 |
| QP-16 | 21 | 26 | 20 | 41.0 | 60 | 20 | 160 | 0.5 |
| QP-16G | 21 | 26 | 18 | 41.0 | 60 | 20 | 160 | 0.5 |
| QP-20 | 25 | 30 | 24 | 49.0 | 80 | 24 | 200 | 1.0 |
| QP-21D | 21 | 30 | 24 | 41.0 | 70 | 20 | 210 | 0.9 |
| QP-30 | 25 | 39 | 28 | 49.0 | 80 | 24 | 300 | 1.0 |
Packing & Delievery :
Packing Details : International standard seaworthy wooden case or per customer requirement.
Delivery Details : 2-6 weeks after order confirmation.
Hebei ChenCheng Power Equipment is one of the earliest, large-scale professional manufacture for high quality electric power fittings since 1990, located in Yongnian “China Fastener &Hardware Capital”
1. We have 2 professional factories area more than 25000m2 , 80 sets of advanced processing machine including full-automatic angle steel line, the production line of steel wire, iron line parts, casting, standard parts, complete test and inspection machines, etc.
2. We are ISO9001:2008 approved, can produce 90 series of(1000 types) of Electric Power Fitting products mainly including overhead cable fitting, Iron hardware, Bolts & Nuts /Rigging/Fastener, ADSS & OPGW Cable Fittings and other OEM items.
3. Our product has been exported to Russia, Middle East and South Asia with highly comment.
Contact Us:
Email:cindy6662021@163.com
whatsapp:+86-18233030851
>>
