Basic Info.
Agitator Model
Combined Agitator
Heating
Outside (Inside) Coil Heating
Heat Transfer Structure
Jacketed
Automatic Grade
Customizable
Cooling,
Water or Materials
Enamel Selection
Acid-Resistant Enamel
Dimensions
Can Be Customized
Transport Package
Wooden Box
Specification
50-50000(L)
Production Capacity
500/Years
Product Description
| specification(L) | Actual capacity(L) | Inner barrel size(mm) | Dimensions(mm) | Reducer model | Motor power | Stirring speed(n/min)
|
| 50 | 61 | 400 | 600 | m3 | 0.6 | 60-80 |
| 100 | 120 | 500 | 700 | m3 | 0.6 | 60-80 |
| 200 | 247 | 600 | 800 | m4 | 1.6 | 60-80 |
| 300 | 355 | 700 | 900 | m4 | 1.5 | 60-80 |
| 500 | 589 | 900 | 1100 | m6 | 2.2 | 60-80 |
| 1000 | 1215 | 1200 | 1400 | m8 | 4 | 60-80 |
| 2000 | 2244 | 1400 | 1600 | m8 | 5.5 | 60-80 |
The above only shows the parameter information of some specifications of the product, if you have other needs, please contact us to customize, thank you!
Product Category:
Pharmaceutical equipment, chemical equipment, food equipment (dairy beverages, condiments, wines), environmental protection equipment.
Product Standards:
Non-standard production of monomers, complete sets, system units and pressure vessels.
Design, production and acceptance criteria:
HG/T20569-1994,HG/T21571.2-2015TSG21-2016,GB150-1998.
Product Selection:
Titanium steel, 304/316L stainless steel, Hastelloy steel, duplex steel, composite plate, etc.
Applicable process:
Stirring, dissolving, neutralization, emulsification, homogenization, mixing, evaporation, crystallization, distillation, hydrogenation, alkylation, polymerization, condensation, constant temperature reaction, etc.
Mounting form:
Outside foot support, platform support, mobile type.
Drive Motor:
According to the working conditions, the simulation calculation formula is used to select the motor power, the number of poles and the brand; And confirm the explosion protection and protection level.
Sealing form:
Single-acting mechanical seals, direct-coupled single-acting mechanical seals, double-acting mechanical seals, and static spring seals for kettles.
Selection of agitator:
According to the process requirements, the working form of the stirring paddle can be selected by hydrodynamic simulation calculation.
If you have any other needs about the product, you can contact us!
>>
