Joston 100L Steel Lined PTFE Pharmaceutical Chemicals Acid Storage Tank

Product Description

PTFE Lined Tank is used to storage or reactor the pharmaceutical solution liquid ,chemical solution etc field ,which is in the high corrosion or strong acid ,the stainless steel material cannot bearing ,so it need inside coated or lined PTFE . also thIs kind PTFE material can fit to GMPs standard requirement ,can used in the food and pharmaceutical field .
Fluoroplastics and metal composite technology is the result of ETFE (F-40). This technology is a new process of rotary sintering forming. According to the different requirements of users, the reasonable formula and the best lining thickness are selected to fuse the plastics and steel matrix. It is characterized by the integration of steel and plastic, strong adhesion, synchronous expansion and contraction, not easy to delamination, lining layer also has no lap joint, no bubbles, no pinholes, high impact strength, good anti permeability, smooth and bright surface, like enamel, small friction coefficient, not easy to scale and other characteristics.
ETFE [F40] is synthesized by copolymerization of 1:1 tetrafluoroethylene and ethylene. ETFE [F-40] fluoroplastics come from DuPont and Asahi, which are mainly used in anti-corrosion lining.
The material has the corrosion resistance of polytetrafluoroethylene and strong adhesion to metal, which overcomes the non adhesion defect of polytetrafluoroethylene to metal and makes ETFE [F-40] an ideal composite material with metal.
The optimized composite technology should be applied to anticorrosion equipment, which fully shows that the equipment manufactured by this technology has excellent negative pressure resistance. Welding steel wire mesh inside the equipment can enhance the anti negative pressure to the greatest extent, and the specific anti negative pressure value is as high as 0.09mpa.
After long-term production practice, it has been proved that the overall one-time roll coating F40 is the most ideal lining
material for reactor, storage tank, tower section and other equipment under the premise of high-temperature alkali,
high-temperature acid and other strong corrosive media, and glass lining can not be used.

Core Components	Pressure vessel
Coating Color	Standard dark green and blue or customized
Acid and alkalinity proof	Standard PH: 3~11, Special PH:1~14
Holiday test	>1500V
Coating Thickness	0.25-0.45 mm
Adhesive power	3450 N/cm
Hardness	6.0 Mohs
service life	30 years

SERVICEWe have established some overseas agent office to make the after-sales serivce already ,so it can will be service client in fast response .also in our headquarter service team ,there is a expert team which can support client in 7*24 hours .
1. Customer inquiry and consultation (URS documents)
2. Confirmation of treatment plan (DQ documents &PID Drawing)
3.Quotation offer with the technolgy document (Quotation PI )
4.Engineering and Manufacturing (Prodcution &Quality inspection )
5. Product inspection (FAT documents)
6. Delivery arrangement and loading work (full set Shipment documents)
7. After-sales service (OQ,PQ ,SAT documents)FAQ1.What about your factory?
Our factory is located in Wenzhou city ,Zhejiang Province and have more than 15 years experience on machinery making.
2.How will your company control the equipment quality ?
We have a qualified expert team ,we will inspect every production proceed .also Machines will be tested in our plant before shipment .
3.How long the warranty will be?
We provide 1 years warranty for the machine running ,but we will afford whole -life service for the machine .
4.Which kind payment do your company do now ?
We accept Western Union, T/T ,D/P,D/C and irrevocable L/C payable etc.
5.Can we become your distributor in our country?
Yes, we very welcome you! More details will be discussed if you are interested in being our agent.
6.Why we choose "JOSTON "?
1. We enhance the reliability of product's quality and working life .
2. We decrease the consumption cost of the product in the ruuning.
3. We improve research personnel's ability to deliver a creative design;
4. We use leading technologies in our product development and innovation, and thereby increase the competitive advantage of products.
7.Do you supply installation equipment in oversea?
Yes, if need, we can send our engineer to your plant to help you do installation and commission.
8.How can we know the order production status ?
We will arrange the person to take photo or video during manufacturing in every week to make you to know the production status.When goods are finished,we will take detailed photos or video for your checking ,after approve ,then we will arrange shipment .also you can arrange FAT in our plant when the goods is ready here
9.what is kind service do you offer before making order ?
1.according to your company URS ,we will make the design drawing accoridingly.
2.after your company approved drawing ,we will make quotation.
3. final we make agreement on payment terms ,delivery time ,package ,shipment etc.
10.how about your company after-sale serivce ?
1. We provide long-term after-sale service.
2. we can do installation and commission for the equipment in your plant if necessary .
3. Meanwhile, you can call or e-mail us to consult on any relevant question since we have a special line for after-sale service. Alternatively, you can communicate on-line with us to solve any problem.

---
