Kneader Rubber Mixing Mill Conveyor Lifter Bucket Elevator for Rubber

Product Description

Kneader Rubber Mixing Mill Conveyor Lifter Bucket Elevator for Rubber
This machine is a kind of Transport Machinery.As an auxiliary engine of Rubber Kneader,it is used for transporting the materials discharged from Rubber Kneader to rubber mixing mill,rubber sheeting mill,extruder or some other machines for processing,it is a component of mixing rubber(plastic) production line.
Machine Features
This machine consists of Motor,Reducer, Machine Driven System of china transmission,Guide Frame,Hopper,Electrial Control parts,etc.The hopper move up and down on the guide frame and turnover driven by the transmission system,two limits switch are on the top and at starting position,to control the hopper.

Technical Parameter

1,Apply to type of Kneader	35L/55L/75L/110L
2,Lifting Speed of Hopper (m/min)	13.8
3,Lifting Weight(kg)	160
4,Speed of Mainshaft(r/min)	25.9
5,Model of Chain	Chain 16A-1
6,Driving Motor Power(KW)	1.5
7,Type of Motor	90L-4

Machine Pictures
Machine Delivery
Related Machines
Our factory is professional in manufacturing different types of plate vulcanizer,also can manufacture rubber cutter,open mixing machine,and kneading machine,etc. Welcome to contact me for more machine details~~

---
