Voice Coil Linear Actuator

Product Details

Product Description

Product Description
Technical parameters
Peak thrust ：6N
Continue to push ：3N
Total trip ：15mm
Force repetition accuracy ：±3g
The force constant ：3 N/A
Linear stroke resolution ：1μm
Position repeat positioning accuracy ：±5μm
No-load frequency ：＞30 Hz
The mechanical parameters
The overall quality :190g
Move the quantity ：30g
size ：80mm×55mm×16mm
Runtime environment
Working voltage ：24V DC±10%
Sustained current ：1.0A
Peak current ：2.0A
Protection grade ：IP40
Recommended Work Environment ：0~40°C，85%RH The following
In line with international standards ：CE,FCC,RoHS

---
