Small Lifting Machines Lightweight Lifting Industrial Scissor Lifts Aerial Platform Swsl1412HD

Product Description

Product Description
SWSL1412HD rough terrain lifting harbour freight Scissor Lifts
Committed to the R&D, manufacturing, sales and after-sales service of high-quality aerial work equipment, the brand focuses on the development of two major product categories: electric scissor type, diesel off-road scissor type, articulating boom type, straight boom type aerial work platforms and telescopic boom forklifts. The working heights of the brand's electric scissor aerial work platforms include 6m, 8m, 10m, 12m and 14m. This series of products travel fast, and have high bearing capacity, strong gradeability and small turning radius, greatly increasing the work efficiency. There are hydraulic drive and electric drive for your choice. Consuming less energy, the electric drive models are more energy-saving and environmentally-friendly. In terms of safety, provided with a tilt protection system, an overload protection system, a pothole protection system, etc., which fully guarantee the safety of the operator, they are ideal for indoor and outdoor applications.
Parameter:

Item		SWSL1212HD	SWSL1412HD	SWSL1614HD
Maximum working height		12m	14m	15.8m
A	Maximum platform height	10m	12m	13.8m
B	Height of retracted platform	1.36m	1.49m	1.53m
C	Length of working platform	2.27m	2.27m	2.64m
	Extension dimension of platform	0.9m	0.9m	0.9m
D	Width of working platform	1.15m	1.15m	1.15m
E	Height - retracted (guardrail raised)	2.49m	2.63m	2.63m
	Height - retracted (guardrail folded)	1.95m	2.09m	2.1m
F	Overall length	2.47m	2.47m	2.84m
G	Overall width	1.17m	1.17m	1.41m
H	Wheel base	1.87m	1.87m	2.24m
I	Ground clearance (retracted state)	0.11m	0.11m	0.12m
J	Ground clearance (extended state)	0.02m	0.02m	0.02m

MORE INFORMATION CONTACT VIA:
[WA] 8616789114921
Detailed Photos
Packaging & Shipping

---
